Connect to private AKS via browser

Question

Connect to private AKS via browser

Celso Silvestre 0

I have a private kubernetes cluster (aks) with a site-to-site vpn established.

Accessing the aks pages in the azure portal stopped working a few weeks ago on chrome. This week it stopped working on edge as well.

Nothing changed on the networking configuration. I can get secrets, namespaces etc via CLI but I cannot visualize that on the browser anymore, getting the following error:

User's image

To clarify, via CLI everything works. Accessing the apps running in the cluster also works, which indicates this might be a portal, browser issue.

Best,

Celso

Manish Deshpande 1,330 Reputation points Microsoft External Staff Moderator

2025-12-10T18:27:53.4333333+00:00
Hello @Celso Silvestre

Thank you for contacting us about the AKS issue.

To summarize the situation:

Your AKS cluster is private, meaning the API server is reachable only over the VNet.

When the portal tries to load the Workloads / Nodes / Deployments panes, it makes direct API calls from your local machine to the cluster’s private endpoint.

If your machine can’t resolve or reach that internal endpoint over the VPN, the Portal UI fails, even though kubectl works (because kubectl uses the kubeconfig endpoint you already authenticated to).

Make sure DNS resolution for the AKS private endpoint is working. The portal needs your browser to resolve the cluster’s private FQDN, and if DNS doesn’t go through the VPN, it will use your public ISP DNS, causing it to fail.

From your machine (while connected to the VPN), run:

nslookup <your-private-cluster-fqdn>

You should get a 10.x.x.x IP (or whatever range your AKS VNet uses).

If it resolves to a public IP or fails to resolve, then DNS is the culprit.

Make sure your internal DNS servers are configured in your VPN client profile.

If you’re using Azure Private DNS Zones, ensure that the DNS forwarder/firewall on‑prem forwards privatelink.<region>.azmk8s.io lookups to Azure.

https://learn.microsoft.com/en-us/azure/architecture/guide/security/access-azure-kubernetes-service-cluster-api-server

2. Confirm the VPN is forwarding Browser Traffic

A VPN tunnel may come up while the split‑tunnel route omits the AKS subnet(s). In that case, CLI access (via kubeconfig IPs) works, but browser access fails.

Ensure your VPN routing table includes:

The AKS VNet

The AKS node subnet

The private AKS API endpoint subnet

If DNS resolves but routing doesn’t, the browser will hang or show the same error as in your screenshot.

Update your VPN routing so all traffic to the AKS VNet(s) is forwarded.
If using split‑tunneling:

Add the AKS private endpoint subnet, or

Switch temporarily to full‑tunnel mode to confirm the issue.

3.Test connectivity to the private API server directly

Once DNS looks right, test whether you can reach the API server over port 443:

curl -v https://<private-fqdn>:443

Because the AKS Portal tab is rendered using multiple embedded API calls, Chrome/Edge caching can sometimes cause repeated failures.

Try the following:

Open Chrome/Edge → Incognito (important).

Navigate to the AKS resource → Workloads.

If this works in incognito, clear browser cache or disable problematic extensions.

This aligns with cases where:

kubectl works

VPN is healthy

Only the Portal UI fails.

5**.If your AKS cluster uses Azure Private DNS (default for private clusters), confirm:**

The Private DNS zone is still linked to the VNet hosting your VPN gateway

No accidental unlinking or stale link from recent resource moves

If the VNet link breaks, DNS resolution works only inside Azure but not from on‑prem.

References
https://learn.microsoft.com/en-us/azure/aks/network-isolated?pivots=aks-managed-acr
https://learn.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-troubleshoot-vpn-point-to-site-connection-problems

Thanks,
Manish
Manish Deshpande 1,330 Reputation points Microsoft External Staff Moderator

2025-12-11T23:10:57.49+00:00

Hello @Celso Silvestre

I wanted to check if my last response made sense. I’d be glad to assist further or explain anything in more detail
Celso Silvestre 0 Reputation points

2025-12-12T10:51:25.5566667+00:00

Hi Manish,

Thanks for your help.
It is not a dns issue.
I just gave it a try on firefox and in firefox it still works. I noticed on the network tab on chrome and on edge CORS errors. It is definitely something related to blocking requests to private endpoints (I noticed the same today while connecting to azure key vault, etc).

Best,

Celso

1 answer

Your answer

Manish Deshpande 1,330 Reputation points Microsoft External Staff Moderator

2025-12-11T23:10:57.49+00:00

Hello @Celso Silvestre

I wanted to check if my last response made sense. I’d be glad to assist further or explain anything in more detail
Celso Silvestre 0 Reputation points

2025-12-12T10:51:25.5566667+00:00

Hi Manish,

Thanks for your help.
It is not a dns issue.
I just gave it a try on firefox and in firefox it still works. I noticed on the network tab on chrome and on edge CORS errors. It is definitely something related to blocking requests to private endpoints (I noticed the same today while connecting to azure key vault, etc).

Best,

Celso

Answer 1

Rodrigo Werlang 0

@Celso Silvestre I had the same issue.
What solved it was allowing the Azure Portal in the browser to use my location. This solved the issue.
If that works, please mark it as the solution.
