How to do encrypt and decrypt data using Cryptography API Next Generation (CNG) in C#?

Question

Hi Team,
How to implement encrypt and decrypt mechanism using CNG ( Cryptography API Next Generation) in C#.Net?

below link about CNG:
https://learn.microsoft.com/en-us/windows/win32/seccng/about-cng

Please help me on this.

Regards,
Prabhakaran

Answer 1

You can refer to https://learn.microsoft.com/en-us/windows/win32/seccng/encrypting-data-with-cng

Answer 2

Hi @Prabs ,

How to implement encrypt and decrypt mechanism using CNG ( Cryptography API Next Generation) in C#.Net?

You can refer to the following two documents.
https://learn.microsoft.com/en-us/dotnet/api/system.security.cryptography.aescng provides a CNG implementation of the Aes algorithm(SymmetricAlgorithm).
https://learn.microsoft.com/en-us/dotnet/api/system.security.cryptography.rsacng provides a CNG implementation of the RSA algorithm(AsymmetricAlgorithm).
Hope the documents could be helpful.
Best Regards.
Jiachen Li

----------

If the answer is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Answer 3

Hi @Prabs ,
Here is a test example of AesCng https://github.com/er0dr1guez/corefx/blob/master/src/System.Security.Cryptography.Cng/tests/InvasiveCngTests.cs.
And here is an implementation case of AesCng encryption and decryption which you can refer to.

        private String Encrypt_String_By_AesCng_Engine02(String PlainText,
                             String Password,
                              String Salt = "Kosher",
                             String HashAlgorithm = "SHA1",
                             int PasswordIterations = 2,
                             String InitialVector = "OFRna73m*aze01xY",
                             int KeySize = 256)
        {
        if (String.IsNullOrEmpty(PlainText)) return "";
            byte[] InitialVectorBytes = Encoding.ASCII.GetBytes(InitialVector);
            byte[] SaltValueBytes = Encoding.ASCII.GetBytes(Salt);
            byte[] PlainTextBytes = Encoding.UTF8.GetBytes(PlainText);
            PasswordDeriveBytes DerivedPassword = new PasswordDeriveBytes(Password, SaltValueBytes, HashAlgorithm, PasswordIterations);
            SHA256Managed sHA256Managed = new SHA256Managed();
            byte[] KeyBytes = sHA256Managed.ComputeHash(Encoding.Unicode.GetBytes(Password));

        AesCng SymmetricKey = new AesCng();
            SymmetricKey.Mode = CipherMode.CBC;
            byte[] CipherTextBytes;
            using (ICryptoTransform Encryptor = SymmetricKey.CreateEncryptor(KeyBytes, InitialVectorBytes))
            {
                using (MemoryStream MemStream = new MemoryStream())
                {
                    using (CryptoStream CryptoStream = new CryptoStream(MemStream, Encryptor, CryptoStreamMode.Write))
                    {
                        CryptoStream.Write(PlainTextBytes, 0, PlainTextBytes.Length);
                        CryptoStream.FlushFinalBlock();
                        CipherTextBytes = MemStream.ToArray();
                        MemStream.Close();
                        CryptoStream.Close();
                    }
                }
            }
            SymmetricKey.Clear();
        return Convert.ToBase64String(CipherTextBytes);
        }

        private String Decrypt_String_By_AesCng_Engine02(String CipherText,
                     String Password,
                      String Salt = "Kosher",
                     String HashAlgorithm = "SHA1",
                     int PasswordIterations = 2,
                     String InitialVector = "OFRna73m*aze01xY",
                     int KeySize = 256)
        {
            if (String.IsNullOrEmpty(CipherText))return "";
            byte[] InitialVectorBytes = Encoding.ASCII.GetBytes(InitialVector);
            byte[] SaltValueBytes = Encoding.ASCII.GetBytes(Salt);
            byte[] CipherTextBytes = Convert.FromBase64String(CipherText);
            PasswordDeriveBytes DerivedPassword = new PasswordDeriveBytes(Password, SaltValueBytes, HashAlgorithm, PasswordIterations);
            SHA256Managed sHA256Managed = new SHA256Managed();
            byte[] KeyBytes = sHA256Managed.ComputeHash(Encoding.Unicode.GetBytes(Password));

            AesCng SymmetricKey = new AesCng();
            SymmetricKey.Mode = CipherMode.CBC;
            byte[] PlainTextBytes = new byte[CipherTextBytes.Length - 1];
            int ByteCount = 0;

            using (ICryptoTransform Decryptor = SymmetricKey.CreateEncryptor(KeyBytes, InitialVectorBytes))
            {
                using (MemoryStream MemStream = new MemoryStream(CipherTextBytes))
                {
                    using (CryptoStream CryptoStream = new CryptoStream(MemStream, Decryptor, CryptoStreamMode.Read))
                    {
                        ByteCount = CryptoStream.Read(PlainTextBytes, 0, PlainTextBytes.Length);
                        MemStream.Close();
                        CryptoStream.Close();
                    }
                }
            }
            SymmetricKey.Clear();
            return Encoding.UTF8.GetString(PlainTextBytes, 0, ByteCount);
        }

Hope the code above colud be helpful.
Best Regards.
Jiachen Li

----------

If the answer is helpful, please click "Accept Answer" and upvote it.
Note: Please follow the steps in our documentation to enable e-mail notifications if you want to receive the related email notification for this thread.

Answer 4

Hi @Prabs ,
I made some simplifications and modifications on the previous example, and it can now run correctly.
You can refer to the following code.

        public string Encrypt(string PlainText, String Salt = "Kosher", String InitialVector = "OFRna73m*aze01xY")
        {
            if (string.IsNullOrEmpty(PlainText))
            {
                return string.Empty;
            }
            SHA256Managed sHA256Managed = new SHA256Managed();
            byte[] key = sHA256Managed.ComputeHash(Encoding.ASCII.GetBytes(Salt));
            byte[] iv = Encoding.ASCII.GetBytes(InitialVector);

            using (var SymmetricKey = new AesCng()
            {
                Key = key,
                IV = iv,
                KeySize = 256,
                BlockSize = 128,
                Mode = CipherMode.CBC,
            })
            {
                using (var transform = SymmetricKey.CreateEncryptor(key, iv))
                {
                    var inputBytes = Encoding.UTF8.GetBytes(PlainText);
                    var encryptedBytes = transform.TransformFinalBlock(inputBytes, 0, inputBytes.Length);
                    return Convert.ToBase64String(encryptedBytes);
                }
            }
        }

        public string Decrypt(string CipherText, String Salt = "Kosher", String InitialVector = "OFRna73m*aze01xY")
        {
            if (string.IsNullOrEmpty(CipherText))
            {
                return string.Empty;
            }
            SHA256Managed sHA256Managed = new SHA256Managed();
            byte[] key = sHA256Managed.ComputeHash(Encoding.ASCII.GetBytes(Salt));
            byte[] iv = Encoding.ASCII.GetBytes(InitialVector);

            using (var SymmetricKey = new AesCng()
            {
                Key = key,
                IV = iv,
                KeySize = 256,
                BlockSize = 128,
                Mode = CipherMode.CBC,
            })
            {
                using (var transform = SymmetricKey.CreateDecryptor(key, iv))
                {
                    var inputBytes = Convert.FromBase64String(CipherText);
                    var PlainTextBytes = transform.TransformFinalBlock(inputBytes, 0, inputBytes.Length);
                    return Encoding.UTF8.GetString(PlainTextBytes);
                }
            }
        }

Hope the code above colud be helpful.
