How to fix overlapping error?

Question

There are no other vnets created in my subscription, I deleted all the resource groups, but still I am getting below error while deploying the template.

{
    "status": "Failed",
    "error": {
        "code": "ServiceCidrOverlapExistingSubnetsCidr",
        "target": "networkProfile.serviceCIDR",
        "message": "The specified service CIDR 10.0.0.0/16 is conflicted with an existing subnet CIDR 10.0.0.0/16"
    }
}

My template:

{
  "$schema": "https://schema.management.azure.com/schemas/2019-04-01/deploymentTemplate.json#",
  "contentVersion": "1.0.0.0",
  "parameters": {
    "clusterName": {
      "type": "string",
      "defaultValue": "aks101cluster",
      "metadata": {
        "description": "The name of the Managed Cluster resource."
      }
    },
    "osDiskSizeGB": {
      "type": "int",
      "defaultValue": 0,
      "maxValue": 1023,
      "minValue": 0,
      "metadata": {
        "description": "Disk size (in GB) to provision for each of the agent pool nodes. This value ranges from 0 to 1023. Specifying 0 will apply the default disk size for that agentVMSize."
      }
    },
    "agentVMSize": {
      "type": "string",
      "defaultValue": "Standard_B4ms",
      "metadata": {
        "description": "The size of the Virtual Machine."
      }
    },
    "kubernetesVersion": {
      "type": "string",
      "defaultValue": "1.7.7",
      "metadata": {
        "description": "The version of Kubernetes."
      }
    },
    "networkPlugin": {
      "type": "string",
      "defaultValue": "azure",
      "allowedValues": ["azure", "kubenet"],
      "metadata": {
        "description": "Network plugin used for building Kubernetes network."
      }
    },
    "enableRBAC": {
      "type": "bool",
      "defaultValue": true,
      "metadata": {
        "description": "Boolean flag to turn on and off of RBAC."
      }
    },
    "enablePrivateCluster": {
      "type": "bool",
      "defaultValue": false,
      "metadata": {
        "description": "Enable private network access to the Kubernetes cluster."
      }
    },
    "enableHttpApplicationRouting": {
      "type": "bool",
      "defaultValue": true,
      "metadata": {
        "description": "Boolean flag to turn on and off http application routing."
      }
    },
    "enableAzurePolicy": {
      "type": "bool",
      "defaultValue": false,
      "metadata": {
        "description": "Boolean flag to turn on and off Azure Policy addon."
      }
    },
    "networkPolicy": {
      "type": "string",
      "defaultValue": "azure",
      "metadata": {
        "description": "Network policy used for building Kubernetes network."
      }
    },
    "serviceCidr": {
      "type": "string",
      "defaultValue": "10.0.0.0/16",
      "metadata": {
        "description": "A CIDR notation IP range from which to assign service cluster IPs."
      }
    },
    "dnsServiceIP": {
      "type": "string",
      "defaultValue": "10.0.0.10",
      "metadata": {
        "description": "Containers DNS server IP address."
      }
    },
    "dockerBridgeCidr": {
      "type": "string",
      "defaultValue": "172.17.0.1/16",
      "metadata": {
        "description": "A CIDR notation IP for Docker bridge."
      }
    }
  },
  "variables": {
    "location": "[resourceGroup().location]",
    "dnsPrefix": "[toLower(format('{0}-{1}', parameters('clusterName'), uniqueString(resourceGroup().id, parameters('clusterName'))))]",
    "virtualNetworkName": "MyVNET"
  },
  "functions": [],
  "resources": [
    {
      "type": "Microsoft.ContainerService/managedClusters",
      "apiVersion": "2020-09-01",
      "dependsOn": [
        "[resourceId('Microsoft.Network/virtualNetworks', variables('virtualNetworkName'))]"
      ],
      "name": "[parameters('clusterName')]",
      "location": "[variables('location')]",
      "identity": {
        "type": "SystemAssigned"
      },
      "properties": {
        "kubernetesVersion": "[parameters('kubernetesVersion')]",
        "enableRBAC": "[parameters('enableRBAC')]",
        "dnsPrefix": "[variables('dnsPrefix')]",
        "agentPoolProfiles": [
          {
            "name": "agentpool",
            "osDiskSizeGB": "[parameters('osDiskSizeGB')]",
            "count": 1,
            "enableAutoScaling": true,
            "minCount": 1,
            "maxCount": 2,
            "vmSize": "[parameters('agentVMSize')]",
            "osType": "Linux",
            "mode": "System",
            "storageProfile": "ManagedDisks",
            "type": "VirtualMachineScaleSets",
            "availabilityZones": ["1", "2", "3"],
            "vnetSubnetID": "[resourceId('Microsoft.Network/virtualNetworks/subnets', variables('virtualNetworkName'), 'default')]"
          }
        ],
        "networkProfile": {
          "loadBalancerSku": "standard",
          "networkPlugin": "[parameters('networkPlugin')]",
          "networkPolicy": "[parameters('networkPolicy')]",
          "serviceCidr": "[parameters('serviceCidr')]",
          "dnsServiceIP": "[parameters('dnsServiceIP')]",
          "dockerBridgeCidr": "[parameters('dockerBridgeCidr')]"
        },
        "apiServerAccessProfile": {
          "enablePrivateCluster": "[parameters('enablePrivateCluster')]"
        },
        "addonProfiles": {
          "httpApplicationRouting": {
            "enabled": "[parameters('enableHttpApplicationRouting')]"
          },
          "azurepolicy": {
            "enabled": "[parameters('enableAzurePolicy')]"
          }
        }
      },
      "tags": {
        "Owner": "uday",
        "purpose": "automation of server"
      }
    },
    {
      "apiVersion": "2020-11-01",
      "name": "[variables('virtualNetworkName')]",
      "type": "Microsoft.Network/virtualNetworks",
      "location": "[variables('location')]",
      "properties": {
        "subnets": [
          {
            "name": "default",
            "id": "[resourceId('Microsoft.Network/virtualNetworks/subnets', variables('virtualNetworkName'), 'default')]",
            "properties": {
              "addressPrefix": "[parameters('serviceCidr')]"
            }
          }
        ],
        "addressSpace": {
          "addressPrefixes": ["10.0.0.0/8"]
        }
      },
      "tags": {}
    }
  ],
  "outputs": {
    "controlPlaneFQDN": {
      "type": "string",
      "value": "[reference(resourceId('Microsoft.ContainerService/managedClusters', parameters('clusterName'))).fqdn]"
    }
  }
}

Please suggest how to fix this.

Answer 1

@uday kiran reddy , thank you for your question.

The service CIDR A CIDR notation IP range from which to assign Service Cluster IPs. In your case, the service CIDR is defined as:

     "serviceCidr": {
       "type": "string",
       "defaultValue": "10.0.0.0/16",
       "metadata": {
         "description": "A CIDR notation IP range from which to assign service cluster IPs."
       }
     },

On the other hand the AKS virtual network subnet IP range is used to assign private IP addresses to the AKS nodes. In your template, the AKS virtual network subnet IP address range is defined as:

         "subnets": [
           {
             "name": "default",
             "id": "[resourceId('Microsoft.Network/virtualNetworks/subnets', variables('virtualNetworkName'), 'default')]",
             "properties": {
               "addressPrefix": "[parameters('serviceCidr')]"
             }
           }
         ]

where you have defined the AKS subnet address prefix (address range) same as the service CIDR range. This in effect means that the node private IP addresses will be allocated from the same address range as Services in the AKS cluster and there might be some nodes with the same private IP address as some Services. This will result in confusing iptable rules in the nodes and traffic flow to the Services exposing your pods might be faulty.

The ServiceCidrOverlapExistingSubnetsCidr prevents such a deployment of an AKS cluster. Please provide a service CIDR which does not overlap your AKS virtual network subnet's address prefix.

----
Hope this helps.

Please "Accept as Answer" if it helped, so that it can help others in the community looking for help on similar topics.
