I am trying to move data from a RESTFul API running on my on-prem application to ADB with ADF. I have installed self-paced IR in my private network to run the activity/pipeline. Now in one of my API requires form-data to submit in POST call. Equivalent Postman looks like below
Can you please suggest how to perform the same in ADF(As I will be running in self-paced IR dataflow is not applicable). I am trying with "Web" Activity but dont know how to pass form data in it. please help.
The curl command is as below
curl --location --request POST 'http://xxxxxx:8080/security/token' \
--header 'Connection: keep-alive' \
--header 'Accept: application/json' \
--header 'Origin: http://xxxxxxx:8080' \
--form 'grant_type="password"' \
--form 'client_id="xxweb"' \
--form 'client_secret="xxweb"' \
--form 'username="xxx_admin"' \
--form 'password="xxxxxxx"
Hello @Suman Mukherjee ,
Thanks for the question and using MS Q&A platform.
As we understand the ask here is to know how to pass the form data content type in Web activity , please do let us know if its not accurate
I do not have an API to test that , but I think you will have update the header to use "multipart/form-data" and also have pass the data in a very specfic format . Please do read the below blog as I think it should help .
https://www.outsystems.com/blog/posts/consuming-multipart-form-data-rest-method/ .
Also what is the response type of the API is question , is it JSON . Just to let you know that ADF web activitry at this time only accepts JSON in response .
https://learn.microsoft.com/en-us/azure/data-factory/control-flow-web-activity#type-properties
Please do let me if you have any queries.
Thanks
Himanshu
Hello @Suman Mukherjee ,
We haven’t heard from you on the last response and was just checking back to see if you have a resolution yet .In case if you have any resolution please do share that same with the community as it can be helpful to others . Otherwise, will respond back with the more details and we will try to help .
Thanks
Himanshu
Hi @HimanshuSinha-msft ,
I am also working on similar type of request where need to send multipart request via ADF. Link shared by you is more about API but can you help me how we can do via ADF.
Thanks in advance
Hi Himanshu,
I am also working on similar type of request where need to send multipart request via ADF. Link shared by you is more about API but can you help me how we can do via ADF.
Thanks in advance
I am working on the same lines and using PATCH to update data in the form data format. please share if there is a possible solution in ADF
