UWP - There are "ContentControl" items in GridView, when do "Drag and Drop", the item will be disappeared.

Question

Hello,

I implemented "drag and drop" and "ContentControl" on GridView and used "Canreorder=True" property to change item's position.
When the first of "drag and drop", the item will be disappeared. Then, the second of "drag and drop", it will return to normal.

Because I need to use a instance object to do something in ViewModel, "ContentControl" is my way. Or is any else better way?

MainPage.xaml

<GridView
            x:Name="grid"
            Margin="100,10,0,10"
            AllowDrop="True"
            CanDragItems="True"
            CanReorderItems="True"
            IsSwipeEnabled="True"
            ItemsSource="{x:Bind ViewModel.PreviewItems}">
            <GridView.ItemTemplate>
                <DataTemplate>
                    <Grid
                        Width="340"
                        Height="240"
                        Padding="5,0,5,0"
                        BorderThickness="1">
                        <Grid.RowDefinitions>
                            <RowDefinition Height="50" />
                            <RowDefinition Height="180" />
                        </Grid.RowDefinitions>

                        <ContentControl
                            Grid.Row="1"
                            HorizontalAlignment="Left"
                            VerticalAlignment="Top"
                            Content="{Binding ImageThumbnail}" />
                    </Grid>

                </DataTemplate>
            </GridView.ItemTemplate>
            <GridView.ItemsPanel>
                <ItemsPanelTemplate x:Name="clu">
                    <ItemsWrapGrid MaximumRowsOrColumns="5" Orientation="Horizontal" />
                </ItemsPanelTemplate>
            </GridView.ItemsPanel>
        </GridView>

MainViewModel.cs

public class MainViewModel : ObservableObject
    {
        public ObservableCollection<PreviewItem> PreviewItems = new ObservableCollection<PreviewItem>();
        public MainViewModel()
        {
            for (int i = 0; i < 2; i++)
            {
                var item = new PreviewItem();
                item.ImageThumbnail = new Windows.UI.Xaml.Controls.Image();
                ImageSource result = new BitmapImage(new Uri("ms-appx:///Assets/Square150x150Logo.png"));
                item.ImageThumbnail.Source = result;

                PreviewItems.Add(item);
            }
        }
    }

PreviewItem.cs

public class PreviewItem : ObservableObject
{
        private Image _imageThumbnail;
        public Image ImageThumbnail { get => _imageThumbnail; set => SetProperty(ref _imageThumbnail, value); }


        public PreviewItem()
        {
        }

}

Here is my source code.
https://github.com/houzhiwei/UWPProject

Answer 1

I have tested that use ContentControl to repace ContentPresenter in your previous case, It's still a binding issue that place the control in the model class.
The solutuion base on your previous case is that replace ItemsWrapGrid with WrapGrid (still use ContentPresenter as container), the following line could disable virtualization behavior and make drag and drop avaiable for ContentPresenter

<ItemsPanelTemplate x:Name="clu">
    <WrapGrid Orientation="Horizontal"/>
</ItemsPanelTemplate>

Thanks
Nico
