C# and Large Array >4GB

Question

I'm working with C# in VS2022 Enviroment.
I have a program that uses large array and pass these array to mkl dll.
It seams debugging that C part receive a wrong data after 4GB block.

Any one have faced this kind of problem?

It seams C# cannot alloc a block of memory more than 4G contiguously.
Or is it possible that the parameter declaration in C# is not properly configured?

gcAllowVeryLargeObjects = true was alredy configured, and also that the program is compiled for x64 platform.

This is how variables are declared in C#:

    int MAX_SIZE = 16385; //limit 16385
    Complex[,] A = new Complex[MAX_SIZE, MAX_SIZE];
    Complex[] b = new Complex[MAX_SIZE];

The arrays are populated than passed to the dll.

This is the dll declaration in C#:

  [DllImport("mkl_rt.2.dll", ExactSpelling = true, SetLastError = false, CallingConvention = CallingConvention.Cdecl)]
        internal static extern int LAPACKE_zgesvxx(
            int matrix_layout,
            char fact,
            char trans,
            Int64 n,
            Int64 nrhs,
            [In, Out] Complex* A,
            Int64 lda,
            [In, Out] Complex* af,
            Int64 ldaf,
            Int64[] ipiv,
            ref char equed,
            [In, Out] double* r,
            [In, Out] double* c,
            [In, Out] Complex* B,
            Int64 ldb,
            [In, Out] Complex* x,
            Int64 ldx,
            ref double rcond,
            ref double rpvgrw,
            [In, Out] double[] berr,
            Int64 n_err_bnds,
            [In, Out] double[] err_bnds_norm,
            [In, Out] double[] err_bnds_comp,
            Int64 nparams,
            [In, Out] double[] parameters
        );

Thank you

Answer 1

from the docs you have two restrictions, max array dimension size, and default allocation:

The array size is limited to a total of 4 billion elements, and to a maximum index of 0X7FEFFFFF in any given dimension (0X7FFFFFC7 for byte arrays and arrays of single-byte structures).

.NET Framework only: By default, the maximum size of an Array is 2 gigabytes (GB). In a 64-bit environment, you can avoid the size restriction by setting the enabled attribute of the gcAllowVeryLargeObjects configuration element to true in the run-time environment.

Answer 2

Dear Bruce, this is what I read.

By the way, I resolved the problem making many tries and I've discovered this:

what I've understandood is that C# manages array 2D (n dimension?) contiguosly if the size is less than 4GB (because it works).
Than, if the size is upper, this is not more valid, each dimension has a potential different allocated block (strange).
In conclusion the 2D array pointer is not reliable.

Infact, when I've tested the values C# side the values were correct, and this let me think that all pointers were correct too.

the solution was replacing the 2D array with a 1D Array

Before

Complex[,] A = new Complex[MAX_SIZE, MAX_SIZE];

After

Complex[,] A = new Complex[MAX_SIZE * MAX_SIZE];

consider that the pointer is passed to the function

fixed (Complex* ptr_a = &A[0])
