Remote Desktop does not communicate

Question

Hello,

I have several Servers I could not reach using RDP.

• I tried with and without using a jump box.
• The Windows Firewall is OFF
• The network firewall is opened as the flow is complete when checking it... The Network team has checked and rechecked...
• The Credentials are working, as when using the vCenter to Log to the server it works...

Any idea?
Thanks,

Dom

Answer 1

Might try from PowerShell from both source and target. (use target address in both cases)

Test-NetConnection -ComputerName "192.168.49.142" -CommonTCPPort "RDP" -InformationLevel "Detailed"

Answer 2

Hello,

The issue was with a certificate expired...
Under mmc > certificates > Computer > Remote Desktop > Certificates

Thanks,
Dom

Answer 3

Hello,

Server Rebooted.
Still all RDP attempts failed.

Thanks,
Dom

Answer 4

Hello,

From the jumpbox to the client:

================================================================

PS C:\Windows\system32> Test-NetConnection -ComputerName "10.16.96.17" -CommonTCPPort "RDP" -InformationLevel "Detailed"

ComputerName : 10.16.96.17
RemoteAddress : 10.16.96.17
RemotePort : 3389
NameResolutionResults : 10.16.96.17
MatchingIPsecRules :
NetworkIsolationContext : Private Network
InterfaceAlias : Ethernet0
SourceAddress : 10.16.101.101
NetRoute (NextHop) : 10.16.101.1
TcpTestSucceeded : True

==================================================================

From the Client to the jumpbox:

==================================================================

Test-NetConnection -ComputerName "10.16.101.101" -CommonTCPPort "RDP" -InformationLevel "Detailed"

ComputerName : 10.16.101.101
RemoteAddress : 10.16.101.101
RemotePort : 3389
NameResolutionResults : 10.16.101.101
MatchingIPsecRules :
NetworkIsolationContext : Private Network
InterfaceAlias : Ethernet0
SourceAddress : 10.16.96.17
NetRoute (NextHop) : 10.16.96.1
TcpTestSucceeded : True

=================================================================

Thanks,
Dom
