Microsoft Azure Attestation troubleshooting guide

Error handling in Azure Attestation is implemented following Microsoft REST API guidelines. The error response returned by Azure Attestation APIs contains HTTP status code and name/value pairs with the names “code” and “message”. The value of “code” is human-readable and is an indicator of the type of error. The value of “message” intends to aid the user and provides error details.

If your issue isn't addressed in this article, you can also submit an Azure support request on the Azure support page.

HTTP–401: Unauthorized exception

HTTP status code

401

Error code Unauthorized

Scenario examples

  • Unable to manage attestation policies as the user isn't assigned with appropriate roles
  • Unable to manage attestation policy signers as the user isn't assigned with appropriate roles

User with Reader role trying to edit an attestation policy in PowerShell

Set-AzAttestationPolicy : Operation returned HTTP Status Code 401
At line:1 char:1
+ Set-AzAttestationPolicy -Name $attestationProvider -ResourceGroupName ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
  + CategoryInfo          : CloseError: (:) [Set-AzAttestationPolicy], RestException
  + FullyQualifiedErrorId : Microsoft.Azure.Commands.Attestation.SetAzureAttestationPolicy

Troubleshooting steps

In order to manage policies, an Azure AD user requires the following permissions for "Actions":

  • Microsoft.Attestation/attestationProviders/attestation/read

  • Microsoft.Attestation/attestationProviders/attestation/write

  • Microsoft.Attestation/attestationProviders/attestation/delete

    To perform these actions, an Azure AD user must have "Attestation Contributor" role on the attestation provider. These permissions can also be inherited with roles such as "Owner" (wildcard permissions), "Contributor" (wildcard permissions) on the subscription/ resource group.

In order to read policies, an Azure AD user requires the following permission for "Actions":

  • Microsoft.Attestation/attestationProviders/attestation/read

    To perform this action, an Azure AD user must have "Attestation Reader" role on the attestation provider. Read permissions are also part of roles such as "Reader" (wildcard permissions) on the subscription/ resource group.

To verify the roles in PowerShell, run the below steps:

a. Launch PowerShell and log into Azure via the "Connect-AzAccount" cmdlet

b. Refer to the guidance here to verify your Azure role assignment on the attestation provider

c. If you don't find an appropriate role assignment, follow the instructions in here

HTTP – 400 errors

HTTP status code

400

There are different reasons why a request may return 400. Here are some examples of errors returned by Azure Attestation APIs.

Attestation failure due to policy evaluation errors

Attestation policy includes authorization rules and issuance rules. Enclave evidence is evaluated based on the authorization rules. Issuance rules define the claims to be included in attestation token. If claims in enclave evidence don't comply with authorization rules, attest calls will return policy evaluation error.

Error code PolicyEvaluationError

Scenario examples When claims in the enclave quote don't match with the authorization rules of attestation policy

Native operation failed with 65518: G:\Az\security\Attestation\src\AttestationServices\Instance\NativePolicyWrapper\NativePolicyEngine.cpp(168)\(null)!00007FF801762308: (caller: 00007FF80143DCC8) Exception(0) 83FFFFEE Policy Evaluation Error has occurred Msg:[Policy Engine Exception: A Deny claim was issued, authorization failed.]

G:\Az\security\Attestation\src\AttestationServices\Instance\Enclave\api.cpp(840)\(null)!00007FF801739FF3: (caller: 00007FF801232801) LogHr(0) 83FFFFEE Policy Evaluation Error has occurred Msg:[Unhandled Enclave Exception: "Policy Evaluation Error has occurred"]

Troubleshooting steps Users can evaluate enclave evidence against an SGX attestation policy before configuring the same.

Send a request to attest API by providing policy text in “draftPolicyForAttestation” parameter. The AttestSgxEnclave API will use this policy document during the attest call and this can be used to test attestation policies before they are consumed. The attestation token generated when this field is present will be unsecured.

See attestation policy examples

Attestation failure due to invalid input

Error code InvalidParameter

Scenario examples SGX attestation failure due to invalid input. Here are some examples of error messages:

  • The specified quote was invalid due to an error in the quote collateral
  • The specified quote was invalid because the device on which the quote was generated does not meet the Azure baseline requirements
  • The specified quote was invalid because the TCBInfo or QEID provided by the PCK Cache Service was invalid

Troubleshooting steps

Microsoft Azure Attestation supports attestation of SGX quotes generated by Intel SDK and Open Enclave SDK.

Refer to code samples for performing attestation using Open Enclave SDK/ Intel SDK

Invalid certificate chain error while uploading policy/policy signer

Error code InvalidParameter

Scenario examples Configure signed policy or add/delete policy signer, which is signed with an invalid certificate chain (for example, when the Basic Constraints extension of the root certificate is not set to Subject Type = CA)

Native operation failed with 65529: C:\source\src\AttestationServices\Instance\SgxPal\sgxcert.cpp(1074)\(null)!00007FFA285CDAED: (caller: 00007FFA285C36E8) Exception(0) 83FFFFF9 The requested item is not found    Msg:[Unable to find issuer certificate CN=attestationsigningcert]
C:\source\src\AttestationServices\Instance\Enclave\api.cpp(618)\(null)!00007FFA286DCBF8: (caller: 00007FFA285860D3) LogHr(0) 83FFFFF9 The requested item is not found    Msg:[Unhandled Enclave Exception: "The requested item is not found"]
At line:1 char:1
+ Set-AzAttestationPolicy -Name "testpolicy1" -ResourceGroupName "BugBa ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    + CategoryInfo          : CloseError: (:) [Set-AzAttestationPolicy], RestException
    + FullyQualifiedErrorId : Microsoft.Azure.Commands.Attestation.SetAzureAttestationPolicy

Troubleshooting steps The root certificate must be flagged as being issued by a CA (the X.509 basic constraints), else it will not be considered as a valid certificate.

Ensure that the Basic Constraints extension of the root certificate is set to indicate that Subject Type = CA

Else the certificate chain is considered to be invalid.

See policy signer and policy examples

Add/Delete policy signer failure

Error code InvalidOperation

Scenario examples

When user uploads JWS without "maa-policyCertificate" claim

Add-AzAttestationPolicySigner : Operation returned HTTP Status Code 400
Code: InvalidOperation
Message: Native operation failed with 74: ..\Enclave\enclave.cpp(2213)\(null)!: (caller: ) Exception(0) 83FF004A Bad
message    Msg:[Could not find "maa-policyCertificate" claim in policy token]
..\Enclave\api.cpp(496)\(null)!: (caller: ) LogHr(0) 83FF004A Bad message    Msg:[Unhandled Enclave Exception: "Bad
message"]
At line:1 char:1
+ Add-AzAttestationPolicySigner -Name $attestationProvider -ResourceGro ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    + CategoryInfo          : CloseError: (:) [Add-AzAttestationPolicySigner], RestException
    + FullyQualifiedErrorId : Microsoft.Azure.Commands.Attestation.AddAzureAttestationPolicySigner

When user does not upload a certificate in JWS format

Add-AzAttestationPolicySigner : Operation returned HTTP Status Code 400
Code: InvalidOperation
Message: Native operation failed with 74: ..\JsonWebToken\jsonwebtoken.cpp(375)\(null)!: (caller: ) LogHr(0) 83FF004A
Bad message    Msg:[RETURN_IF_TRUE('(firstPeriod == std::string::npos)') failed with 0x4a: Malformed JWT: Could not
find first period in the token.]
..\Enclave\enclave.cpp(2106)\(null)!: (caller: ) LogHr(0) 83FF004A Bad message
Msg:[THROW_IF_ERROR('DecomposeJsonWebSignature(&policyJws, encodedJoseHeader, encodedJwsBody, jwsSignature)') failed
with 0x4a: 'Bad message']
..\Enclave\enclave.cpp(2106)\(null)!: (caller: ) Exception(0) 83FF004A Bad message
..\Enclave\api.cpp(496)\(null)!: (caller: ) LogHr(0) 83FF004A Bad message    Msg:[Unhandled Enclave Exception: "Bad
message"]
At line:1 char:1
+ Add-AzAttestationPolicySigner -Name $attestationProvider -ResourceGro ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    + CategoryInfo          : CloseError: (:) [Add-AzAttestationPolicySigner], RestException
    + FullyQualifiedErrorId : Microsoft.Azure.Commands.Attestation.AddAzureAttestationPolicySigner

Troubleshooting steps To add/delete a new policy signer certificate, use RFC7519 JSON Web Token (JWT) with a claim named "x-ms-policyCertificate". Value of the claim is an RFC7517 JSON Web Key, which contains the certificate to be added. JWT must be signed with private key of any of the valid policy signer certificates associated with the provider. See policy signer examples.

Attestation policy configuration failure

Error code PolicyParsingError

Scenario examples Policy provided with incorrect syntax (for example, missing semicolon)/valid JWT policy)

Native operation failed with 65526: ..\NativePolicyWrapper\NativePolicyEngine.cpp(31)\(null)!: (caller: ) Exception(0) 83FFFFF6 Invalid policy was specified    Msg:[Policy Parser Exception Thrown: Offending
symbol: '['
Line: '2', Column: '1'
Failure message: 'mismatched input '[' expecting ';''
Failing rule: 'policy > versionInfo']
..\Enclave\api.cpp(618)\(null)!: (caller: ) LogHr(0) 83FFFFF6 Invalid policy was specified    Msg:[Unhandled Enclave Exception: "Invalid policy was specified"]
At line:1 char:1
+ set-AzAttestationPolicy -Name $attestationProvider -ResourceGroupName ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    + CategoryInfo          : CloseError: (:) [Set-AzAttestationPolicy], RestException
    + FullyQualifiedErrorId : Microsoft.Azure.Commands.Attestation.SetAzureAttestationPolicy

Error code InvalidOperation

Scenario examples Invalid content provided (for example, upload policy/ unsigned policy when policy signing is required)


Native operation failed with 74: ..\Shared\base64url.h(226)\(null)!: (caller: ) Exception(0) 83FF004A Bad message    Msg:[Unknown base64 character: 41 (')')]
..\Enclave\api.cpp(618)\(null)!: (caller: ) LogHr(0) 83FF004A Bad message    Msg:[Unhandled Enclave Exception: "Bad message"]
At line:1 char:1
+ set-AzAttestationPolicy -Name $attestationProvider -ResourceGroupName ...
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    + CategoryInfo          : CloseError: (:) [Set-AzAttestationPolicy], RestException
    + FullyQualifiedErrorId : Microsoft.Azure.Commands.Attestation.SetAzureAttestationPolicy

Troubleshooting steps Ensure that the policy in Text format is UTF-8 encoded.

If policy signing is required, attestation policy must be configured only in RFC7519 JSON Web Token (JWT) format. If policy signing is not required, policy can be configured in text or JWT format.

To configure a policy in JWT format, use JWT with a claim named "AttestationPolicy". Value of the claim is Base64URL encoded version of the policy text. If the attestation provider is configured with policy signer certificates, the JWT must be signed with private key of any of the valid policy signer certificates associated with the provider.

To configure a policy in text format, specify policy text directly.

In PowerShell, specify PolicyFormat as JWT to configure policy in JWT format. Default policy format is Text.

See attestation policy examples and how to author an attestation policy

Az.Attestation installation issues in PowerShell

Unable to install the Az PowerShell module or Az.Attestation PowerShell module in PowerShell.

Error

WARNING: Unable to resolve package source 'https://www.powershellgallery.com/api/v2' PackageManagement\Install-Package: No match was found for the specified search criteria and module name

Troubleshooting steps

PowerShell Gallery has deprecated Transport Layer Security (TLS) versions 1.0 and 1.1.

TLS 1.2 or a later version is recommended.

To continue to interact with the PowerShell Gallery, run the following command before the Install-Module commands

[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12

Policy access/configuration issues in PowerShell

User assigned with appropriate roles. But facing authorization issues while managing attestation policies through PowerShell.

Error

The client with object ID <object Id> does not have authorization to perform action Microsoft.Authorization/roleassignments/write over scope ‘subcriptions/<subscriptionId>resourcegroups/secure_enclave_poc/providers/Microsoft.Authorization/roleassignments/<role assignmentId>’ or the scope is invalid. If access was recently granted, refresh your credentials

Troubleshooting steps

The minimum version of the Az PowerShell modules required to support attestation operations are:

  • Az 4.5.0
  • Az.Accounts 1.9.2
  • Az.Attestation 0.1.8

Run the below command to verify the installed version of all Az modules

Get-InstalledModule

If the versions do not meet the minimum requirement, run the Update-Module PowerShell cmdlet.

Update-Module -Name Az.Attestation
