Use time series feature tables with point-in-time support

With time series feature tables, Databricks Feature Store supports time series and event-based use cases that require point-in-time correctness.

The data used to train a model often has time dependencies built into it. For example, if you are training a model to predict which machines on a factory floor need maintenance, you might have historical datasets that contain sensor measurements and usage data for many machines, along with target labels that indicate if the machine needed service or not. The dataset might contain data for machines both before and after a maintenance service was performed.

When you build the model, you must consider only feature values up until the time of the observed target value (needs service or does not need service). If you do not explicitly take into account the timestamp of each observation, the predictive signal might be lost.

For example, if the joined features are from very old sensor measurements, stale feature values would not clearly indicate when a machine needed maintenance, thus leading to a less accurate model. If the aggregated features contain sensor readings from a timestamp after the detection of a maintenance requirement, the training data will include values measured after the target value was determined. In other words, the model is being trained on data from the future. This is called “data leakage” and can negatively affect the model’s performance.

Time series feature tables include a timestamp key column that ensures that each row in the training dataset represents the latest known feature values as of the row’s timestamp. You should use time series feature tables whenever feature values change over time, for example with time series data, event-based data, or time-aggregated data.

Note

  • Point-in-time lookup functionality is sometimes referred to as “time travel”. The point-in-time functionality in Databricks Feature Store is not related to Delta Lake time travel.
  • To use point-in-time functionality, you must specify time-related keys using the timestamp_keys argument. This indicates that feature table rows should be joined by matching the most recent value for a particular primary key that is not later than the value of the timestamps_keys column, instead of joining based on an exact time match. If you designate a timestamp column as a primary key column, feature store does not apply point-in-time logic to the timestamp column during joins. Instead, it matches only rows with an exact time match instead of matching all rows prior to the timestamp.

Point-in-time lookups help avoid data leakage problems that can arise when a model is trained on feature values that are not available during real-time inference. Data leakage can introduce significant discrepancies in model performance between training and real-time inference. With time series feature tables, you can ensure that a model uses the latest features, based on timestamps you specify, for training.

Consider using time series feature tables if your feature values change over time, for example with time series data, event-based data, or time-aggregated data.

Requirements

Feature Store client v0.3.7 and above.

Create a time series feature table in Databricks Feature Store

To create a time series feature table, the DataFrame or schema must contain a column that you designate as the timestamp key.

fs = FeatureStoreClient()
# user_features_df DataFrame contains the following columns:
# - user_id
# - ts
# - purchases_30d
# - is_free_trial_active
fs.create_table(
  name="ads_team.user_features",
  keys="user_id",
  timestamp_keys="ts",
  features_df=user_features_df,
)

A time series feature table must have one timestamp key and cannot have any partition columns. The timestamp key column must be of TimestampType or DateType and cannot also be a primary key.

Databricks recommends that time series feature tables have no more than two primary key columns to ensure performant writes and lookups.

Update a time series feature table

When writing features to the time series feature tables, your DataFrame must supply values for all features of the feature table, unlike regular feature tables. This constraint reduces the sparsity of feature values across timestamps in the time series feature table.

fs = FeatureStoreClient()
# daily_users_batch_df DataFrame contains the following columns:
# - user_id
# - ts
# - purchases_30d
# - is_free_trial_active
fs.write_table(
  "ads_team.user_features",
  daily_users_batch_df,
  mode="merge"
)

Streaming writes to time series feature tables is supported.

Create a training set with a time series feature table

To perform a point-in-time lookup for feature values from a time series feature table, you must specify a timestamp_lookup_key in the feature’s FeatureLookup, which indicates the name of the DataFrame column that contains timestamps against which to lookup time series features. Databricks Feature Store retrieves the latest feature values prior to the timestamps specified in the DataFrame’s timestamp_lookup_key column and whose primary keys match the values in the DataFrame’s lookup_key columns, or null if no such feature value exists.

feature_lookups = [
  FeatureLookup(
    table_name="ads_team.user_features",
    feature_names=["purchases_30d", "is_free_trial_active"],
    lookup_key="u_id",
    timestamp_lookup_key="ad_impression_ts"
  ),
  FeatureLookup(
    table_name="ads_team.ad_features",
    feature_names=["sports_relevance", "food_relevance"],
    lookup_key="ad_id",
  )
]

# raw_clickstream DataFrame contains the following columns:
# - u_id
# - ad_id
# - ad_impression_ts
training_set = fs.create_training_set(
  raw_clickstream,
  feature_lookups=feature_lookups,
  exclude_columns=["u_id", "ad_id", "ad_impression_ts"],
  label="did_click",
)
training_df = training_set.load_df()

Any FeatureLookup on a time series feature table must be a point-in-time lookup, so it must specify a timestamp_lookup_key column to use in your DataFrame. Point-in-time lookup does not skip rows with null feature values stored in the time series feature table.

Score models with time series feature tables

When you score a model trained with features from time series feature tables, Databricks Feature Store retrieves the appropriate features using point-in-time lookups with metadata packaged with the model during training. The DataFrame you provide to FeatureStoreClient.score_batch must contain a timestamp column with the same name and DataType as the timestamp_lookup_key of the FeatureLookup provided to FeatureStoreClient.create_training_set.

Publish time series features to an online store

You can use FeatureStoreClient.publish_table to publish time series feature tables to online stores. Databricks Feature Store provides the functionality to publish either a snapshot or a window of time series data to the online store, depending on the OnlineStoreSpec that created the online store. The table shows details for each publish mode.

Online store provider Snapshot publish mode Window publish mode
Azure Cosmos DB (v0.5.0 and above) X
Azure MySQL (Single Server) X
Azure SQL Server X

Publish a time series snapshot

This publishes the latest feature values for each primary key in the feature table. The online store supports primary key lookup but does not support point-in-time lookup.

For online stores that do not support time to live, Databricks Feature Store supports only snapshot publish mode. For online stores that do support time to live, the default publish mode is snapshot unless time to live (ttl) is specified in the OnlineStoreSpec at the time of creation.

Publish a time series window

This publishes all feature values for each primary key in the feature table to the online store and automatically removes expired records. A record is considered expired if the record’s timestamp (in UTC) is more than the specified time to live duration in the past. Refer to cloud-specific documentation for details on time-to-live.

The online store supports primary key lookup and automatically retrieves the feature value with the latest timestamp.

To use this publish mode, you must provide a value for time to live (ttl) in the OnlineStoreSpec when you create the online store. The ttl cannot be changed once set. All subsequent publish calls inherit the ttl and are not required to explicitly define it in the OnlineStoreSpec.

Example notebook

Time series feature table example notebook

Get notebook
