Durable functions with pg_durable for Azure HorizonDB (Preview)

pg_durable is the durable execution engine inside Azure HorizonDB. It lets you define long-running, multi-step SQL workflows (embedding pipelines, ETL jobs, AI calls, scheduled jobs, approval flows) and run them with the same reliability guarantees you'd expect from a dedicated orchestrator like Durable Functions, without leaving Postgres.

pg_durable is also the execution layer underneath durable AI pipelines. If you're using AI pipelines, pg_durable is what makes them survive crashes, retry on failure, and resume from the last completed step.

Note

pg_durable is in preview.

What "durable" means

A durable function in pg_durable is persisted to disk every step of the way. That gives you a specific set of guarantees you don't get from a plain BEGIN ... COMMIT block or a cron job:

Survives database crashes and restarts. Completed steps aren't re-executed when the server comes back up. In-progress steps resume from the last checkpoint. Pending steps run when the worker comes back online.
Survives long waits. A workflow can sleep for hours, wait for a cron schedule, or block on an external signal, and still pick up where it left off.
Survives failures. Failed steps can be retried automatically without rerunning the whole function.
Captures identity. A function executes with the privileges of the user who started it, not the privileges of the background worker. Multitenant workloads stay isolated.
Stays observable from SQL. You can inspect status, history, execution count, and outputs through the same interface you use for everything else in HorizonDB: a SELECT statement.

What durability doesn't do automatically: it doesn't make nonidempotent external operations safe to retry on its own. If a step calls an external API that charges money, design the step to be idempotent (for example, by passing an idempotency key).

When to use pg_durable

Use pg_durable when you have to work that:

Takes long enough to fail in the middle (embedding generation across millions of rows, a multi-step ETL job, a backfill).
Needs to be retried on failure without redoing the parts that already succeeded.
Needs to run on a schedule (every hour, every weekday at 9 AM).
Needs to wait for an external event (an approval, a webhook, a signal from another system).
Coordinates multiple steps with branching, joining, or racing.
Is currently implemented as an external orchestrator + a Postgres database, where most of the work is the database part.

If your workload is a single short transactional statement, you don't need pg_durable. Use a regular INSERT / UPDATE.

How it works

A durable function is a graph of steps that you build with a SQL DSL and submit with df.start(). The graph is persisted, then a background worker executes it.

Two key ideas:

Function graph and execution state are stored in HorizonDB itself, in the df and duroxide schemas. Backups, point-in-time restore, and high availability all apply to your workflow state automatically. No separate orchestrator state to manage.
The background worker is started by shared_preload_libraries. It detects the extension after CREATE EXTENSION and begins executing functions. If the database restarts, the worker reattaches to running instances and resumes them.

Note

The execution engine inside pg_durable is built on Duroxide, Microsoft's open-source durable execution runtime for Rust (inspired by the Durable Task Framework and Temporal). The duroxide schema name reflects this: that's where Duroxide persists orchestration history, correlation IDs, and replay state. The deterministic-replay, correlated-event-ID, and durable-timer guarantees you get from pg_durable come directly from Duroxide.

Enable pg_durable

To enable pg_durable on Azure HorizonDB, first configure a parameter group, then create the extension in each database.

Use these setup articles:

Create a parameter group for your server.
Set shared_preload_libraries to include pg_textsearch.
Set azure.extensions to include pg_textsearch.
Apply the parameter group to the server.
Connect to each target database and run:

Create the extension in each database where you want to use it:

CREATE EXTENSION IF NOT EXISTS pg_durable;

CREATE EXTENSION provisions the df schema (function graphs and monitoring views) and the duroxide schema (execution state). The background worker detects the extension within a few seconds and is ready to run functions.

Your first durable function

-- Start a one-step durable function
SELECT df.start('SELECT ''Hello, durable world!''');
-- Returns an 8-character instance ID, for example: a1b2c3d4

-- Check status
SELECT df.status('a1b2c3d4');

-- Get the result
SELECT df.result('a1b2c3d4');

Even a one-step function is durable: if the database restarts after df.start() and before the worker picks it up, the function still runs.

Note

df.start() submits a workflow asynchronously and returns immediately. For multi-step workflows, use df.list_instances(), df.instance_info(), df.status(), or df.result() to confirm completion before validating side effects.

Program model

A durable function is a graph built from steps, operators, and built-in functions. Plain SQL strings are autowrapped, so you don't need to call df.sql() explicitly.

Operators

Operator	Meaning	Example
`~>`	Sequence - run left, then right	`'SELECT 1' ~> 'SELECT 2'`
`&`	Join - run in parallel, wait for all	`'SELECT 1' & 'SELECT 2'`
`\|`	Race - run in parallel, first wins	`fast_query \| df.sleep(30)`
`?>` `!>`	If / else - branch on a boolean condition	`cond ?> then_branch !> else_branch`
`@>`	Loop - repeat forever (prefix operator)	`@> body`
`\|=>`	Name - capture a step's result	`'SELECT id FROM users LIMIT 1' \|=> 'user_id'`

Useful built-ins

Function	Purpose
`df.sleep(seconds)`	Pause for N seconds. Durable across restarts.
`df.wait_for_schedule(cron)`	Wait until the next time a cron expression matches.
`df.wait_for_signal(name, timeout)`	Block until an external `df.signal()` arrives.
`df.http(url, method, body, headers, timeout)`	Make an HTTP call as a durable activity, with retry on transient failure.
`df.if(cond, then, else)`	Conditional branch.
`df.loop(body, cond)`	Repeat while a SQL condition is truthy.
`df.join(a, b)` / `df.race(a, b)`	Parallel and race execution.
`df.join3(a, b, c)`	For three-way parallel execution.
`df.start(body, label, database)`	Submit a durable function and return its instance ID.
`df.cancel(id, reason)`	Cancel a running instance.
`df.status(id)` / `df.result(id)`	Inspect outcome.
`df.explain(input)`	Render the function graph for visualization.

Read more about all pg_durable features.

Variables

|=> captures a step's result with a name; later steps reference it as $name.

SELECT df.start(
    'SELECT 100 AS amount' |=> 'total'
    ~> 'SELECT $total * 2 AS doubled'
);

Usage examples

Multi-step ETL with retries

A daily ETL that cleans up, loads, indexes, and logs:

SELECT df.start(
    'DELETE FROM target WHERE loaded_at < now() - INTERVAL ''1 day'''
    ~> 'INSERT INTO target SELECT * FROM staging'
    ~> 'REINDEX TABLE target'
    ~> 'INSERT INTO etl_log (job, finished_at) VALUES (''nightly'', now())',
    'nightly-etl'
);

If the database restarts between the DELETE and the INSERT, the worker resumes from the INSERT - it doesn't rerun the DELETE.

Scheduled job (cron)

Run a maintenance task every weekday at 9 AM:

SELECT df.start(
    @> (
        df.wait_for_schedule('0 9 * * 1-5')
        ~> 'CALL refresh_materialized_views()'
    ),
    'weekday-refresh'
);

If you want to stop this job, You can run the cancel function.

SELECT df.cancel('a1b2c3d4', 'stop test cron job');

Approval workflow with timeout

Wait up to 24 hours for an external approval signal, then commit or reject:

SELECT df.start(
    'SELECT order_id, total FROM orders WHERE id = 1' |=> 'order'
    ~> df.wait_for_signal('approval', 86400) |=> 'sig'
    ~> df.if(
        'SELECT NOT ($sig::jsonb->>''timed_out'')::boolean
            AND ($sig::jsonb->''data''->>''approved'')::boolean',
        'UPDATE orders SET status = ''approved'' WHERE id = $order_id',
        'UPDATE orders SET status = ''rejected'' WHERE id = $order_id'
    ),
    'order-approval'
);

-- Later, approve from anywhere
SELECT df.signal('a1b2c3d4', 'approval',
                 '{"approved": true, "approver": "jane@contoso.com"}');

Durable HTTP call

df.http() makes external calls as durable activities - 5xx responses, network errors, and timeouts are retried automatically.

SELECT df.start(
    df.http('https://api.example.com/users/123', 'GET') |=> 'user'
    ~> 'INSERT INTO users_cache (data) VALUES (($user::jsonb->>''body'')::jsonb)',
    'fetch-user'
);

Read more about allowed HTTP security in pg_durable.

Observe and operate

Everything is queryable from SQL. There's no separate UI or service to learn.

-- All instances
SELECT * FROM df.list_instances();

-- Filter by status
SELECT * FROM df.list_instances() WHERE status = 'Running';
SELECT * FROM df.list_instances() WHERE status = 'Failed';

-- Detail for one instance
SELECT * FROM df.instance_info('a1b2c3d4');

-- Execution history (useful for retried or looped functions)
SELECT * FROM df.instance_executions('a1b2c3d4', 20);

-- The function graph as it ran
SELECT * FROM df.instance_nodes('a1b2c3d4');

-- System-wide metrics
SELECT * FROM df.metrics();

To check that the worker is alive:

SELECT epoch_id, last_seen_at, now() - last_seen_at AS time_since_last_heartbeat
FROM df._worker_epoch;

A time_since_last_heartbeat under 15 seconds means the worker is healthy. Anything larger, or no rows at all, means the worker is down or hasn't initialized.

Identity and isolation

Durable functions execute with the privileges of the user who submitted them, not with the worker's privileges. pg_durable captures both session_user and current_user at submission time, so functions submitted under a SET ROLE context run with that effective role.

This means:

Users only see and modify data they already have permissions to access.
Non-superusers can't escalate privileges by submitting a durable function.
Multitenant workloads stay isolated as long as your role and grant model is correct.

Interaction with replicas, backup, and PITR

Backup and PITR. Function graph (df schema) and execution state (duroxide schema) are stored in regular tables and are included in HorizonDB backups. A point-in-time restore restores both.
Read replicas. The background worker only runs on the primary. Read replicas can query the df.* monitoring views but don't execute functions.
Failover. After a failover, the worker on the new primary picks up where the old primary left off. Running instances resume from their last checkpoint.

Compared to external orchestrators

Aspect	External orchestrator	`pg_durable`
Deployment	Separate service, separate identity, separate state store	One database
State durability	Orchestrator's storage layer	Same backups, HA, and PITR as your data
Identity	Workers run under a service identity	Functions execute as the submitting user
Failure modes	Network between orchestrator and database	None - same process
Best for	Cross-system orchestration that touches many services	Workloads where most of the work is in or near Postgres

pg_durable isn't trying to replace external orchestrators for cross-system pipelines. It's the right choice when most of the work is database work - embeddings, transforms, AI calls, scheduled maintenance - and adding another service is more cost than benefit.

Limitations during preview

df.http() retries on 5xx and network errors. 4xx responses are returned to the workflow for you to handle; they aren't retried automatically.
The background worker services a single database per instance. Multi-database fan-out is supported through df.start(..., database => 'other_db') from a function running in the worker's database.
Function definitions and execution state aren't portable across major versions of pg_durable during preview. Drain or cancel running instances before upgrading.
