Build message extensions using API

  • Article

Note

API-based message extensions only support search commands.

Message extensions built using API (API-based) use a web service to manage user requests and responses and don't require a bot registration. You can configure and deploy API-based message extensions using Developer Portal for Teams and Teams Toolkit for Visual Studio Code, command line interface (CLI), or Visual Studio. API-based message extensions help your apps to interact directly with third-party data, apps, and services, enhancing its capabilities. With API-based message extension, you can:

  • Retrieve real-time information, such as latest news coverage on a product launch.
  • Retrieve knowledge-based information, for example, my team’s design files in Figma.

You can create an API-based message extension using an OpenAPI Description (OAD) document. After you've created an OpenAPI Description document, use the OpenAPI Description document to generate and integrate the client code in your app's project. Create or generate a response rendering template to manage the responses from the API.

See the video to learn more about building an API-based message extension using Teams Toolkit:

Prerequisites

Before you get started, ensure that you adhere to the following requirements:

OpenAPI Description

The OpenAPI Description (OAD) is the industry-standard specification that details the structure and outline of OpenAPI files. It's a language-agnostic, human-readable format for describing APIs. Both humans and machines can easily read and write the openAPI Description. The schema is machine-readable and can be represented in either YAML or JSON. An OpenAPI Description document is required before creating an API-driven message extension.

Response rendering template

A response rendering template maps JSON responses to a preview card and an Adaptive Card. When a user selects a search result, the preview cards appear as results. The preview card then expands into an Adaptive Card in the message compose box.

Each search command must have a corresponding response rendering template, and each command must correspond to an operation in the OpenAPI Description. However, not every operation defined in an OpenAPI Description must be a command. The response rendering template consists of an Adaptive Card template, preview card template, and metadata and must conform to the Response rendering template schema hosted at https://developer.microsoft.com/json-schemas/teams/vDevPreview/MicrosoftTeams.ResponseRenderingTemplate.schema.json.

Update app manifest

Update app manifest (previously called Teams app manifest) with the composeExtensions property. The following code is an example of the app manifest with the composeExtensions property:

{
  "composeExtensions": [
    {
      "composeExtensionType": "apiBased",
      "apiSpecificationFile": "aitools-openapi.yml",
      "commands": [
        {
          "id": "searchTools",
          "type": "query",
          "context": [
            "compose",
            "commandBox"
          ],
          "title": "search for AI tools",
          "description": "search for AI tools",
          "parameters": [
            {
              "name": "search",
              "title": "search query",
              "description": "e.g. search='tool to create music'"
            }
          ],
          "apiResponseRenderingTemplateFile": "response-template.json"
        }
      ]
    }
  ]
}

Next step

Build API-based message extension
