Handling Two Monitor Configurations

  • Article

A two-monitor configuration generates the Transient Multi-monitor Manager (TMM) dialog. If two targets are part of the same graphics adapter, TMM will map the one source that is currently mapped to one of the targets to both targets. After TMM performs the mapping, the TMM dialog will pop up. If the targets are on different graphics adapters, the TMM dialog will pop up without activating the second monitor. In this situation, the TMM dialog will not have the option for clone or extended.

The following sequence shows the order in which TMM calls the IViewHelper methods and performs other operations in this situation:

  1. TMM calls the EnumDisplayDevices function to retrieve the current display configuration, which includes adapters, displays, and monitors. For more information about EnumDisplayDevices, see the Microsoft Windows SDK documentation.

  2. TMM compares display configuration against the previously recorded display configurations.

  3. If the display configuration has one or two monitors with Extended Display Information Data (EDID) that TMM has not encountered before, TMM proceeds to bring up the TMM dialog.

  4. For each adapter in the display configuration, TMM makes calls to the IViewHelper::GetConnectedIDs method to retrieve all of the sources on the adapter whether the sources are mapped or not.

  5. TMM makes calls to the IViewHelper::GetConnectedIDs method to retrieve all of the targets on the adapter, whether the targets are mapped or not. Each target must be connected but is not required to be active.

  6. For each source in the graphics adapter, TMM makes calls to the IViewHelper::GetActiveTopology method to retrieve the active targets for the source.

  7. TMM finds the graphics adapter that has a source that is mapped to a target. This source identifier is called "CloneSource." If the adapter has two targets, TMM creates an array of two entries (ULONG targetArray[2]). TMM places the existing target identifier as the first element and the second target identifier as the second element.

  8. TMM calls the IViewHelper::SetActiveTopology(adapterName, CloneSource, 2, targetArray) method with the indicated parameters.

  9. TMM calls the IViewHelper::Commit method.

If an error result is returned from any of the IViewHelper methods, the computer does not enter clone view, and the TMM dialog pops up with clone-view and external-only options disabled.

If the computer enters clone view and the user chooses extended view from the TMM dialog (and clicks OK or Apply), TMM must turn off clone view as follows:

  1. TMM calls the IViewHelper::SetActiveTopology(adapterName, CloneSource, 1, targetArray) method with the indicated parameters.

  2. TMM calls the IViewHelper::Commit method.

In the preceding SetActiveTopology call, parameter three is set to 1 and not 2. In this situation, SetActiveTopology interprets targetArray as an array with one element. SetActiveTopology turns off the second target and enters single view. Next, TMM uses the ChangeDisplaySettingsEx function to extend the display. For more information about ChangeDisplaySettingsEx, see the Microsoft Windows SDK documentation.

The following figure shows the flow of operations that occur when TMM handles the situation when a monitor is added to make a two-monitor configuration.

Diagram illustrating the process of adding a monitor to create a two-monitor configuration.
