Starting from the SharePoint Framework v1.23, ListView Command Sets also support grouping. You can use group element and cross item associations in the ListView Command Set manifest to build a hierarchy of commands that are then grouped in the list and library toolbar and context menu.
Caution
This article is related to a pre-release (alpha/beta/release candidate) version of the SharePoint Framework.
For production environments, we recommend using the SPFx version referenced on Set up your SharePoint Framework development environment.
Notice that you can only have two levels of grouping as shown in the picture and in the following sample.
Here's an example extension manifest that uses group element and type to define the associations and grouping between the commands.
{
"$schema": "https://developer.microsoft.com/json-schemas/spfx/command-set-extension-manifest.schema.json",
"id": "5be38d1c-597f-436e-9d1b-c019b3a1a9ed",
"alias": "GroupingCommandSet",
"componentType": "Extension",
"extensionType": "ListViewCommandSet",
// The "*" signifies that the version should be taken from the package.json
"version": "*",
"manifestVersion": 2,
// If true, the component can only be installed on sites where Custom Script is allowed.
// Components that allow authors to embed arbitrary script code should set this to true.
// https://support.office.com/en-us/article/Turn-scripting-capabilities-on-or-off-1f2c515f-5d7e-448a-9fd7-835da935584f
"requiresCustomScript": false,
"items": {
"GROUP_1": {
"title": { "default": "Group One" },
"type": "group"
},
"GROUP_2": {
"title": { "default": "Group Two" },
"type": "group"
},
"GROUP_2_1": {
"title": { "default": "Sub group in Group Two" },
"type": "group",
"group": "GROUP_2"
},
"COMMAND_1": {
"title": { "default": "Command One" },
"type": "command",
"group": "GROUP_1"
},
"COMMAND_2": {
"title": { "default": "Command Two" },
"type": "command",
"group": "GROUP_2"
},
"COMMAND_3": {
"title": { "default": "Command Three" },
"type": "command",
"group": "GROUP_2_1"
},
"COMMAND_4": {
"title": { "default": "Command Four" },
"type": "command",
"group": "GROUP_2_1"
}
}
}
