在自适应卡片中键入提前搜索
自适应卡片中的键入头搜索功能在组件上 Input.ChoiceSet
提供了增强的搜索体验。 它提供用于在搜索字段中输入文本的选项列表。 可以将类型头搜索与自适应卡片合并,以搜索和选择数据。
可以使用类型头搜索进行以下搜索:
静态类型头搜索
静态类型头搜索允许用户从自适应卡片有效负载中指定的 Input.ChoiceSet
值进行搜索。 静态类型头搜索可用于向用户显示多个选项。 静态搜索中的有效负载大小随着有效负载中指定的选项数而增加。
当用户开始输入文本时,将筛选部分匹配输入的选项。 下拉列表突出显示与搜索匹配的输入字符。
下图演示了静态类型头搜索:
动态类型头搜索
动态类型头搜索可用于从大型数据集中搜索和选择数据。 数据集是从卡有效负载中指定的数据集动态加载的。 typeahead 功能有助于在用户键入时筛选出选项。
注意
使用动态搜索(例如基于查询的消息扩展)无法获得丰富的卡体验。
实现类型头搜索
Input.ChoiceSet
是自适应卡中的重要输入组件之一。 可以将 typeahead 搜索控件添加到 Input.ChoiceSet
组件以实现类型头搜索。 可以使用以下选项搜索和选择所需信息:
- 下拉列表,例如展开的选择。
- 单选按钮,例如单选按钮。
- 复选框,例如多个选择。
注意
- 控件
Input.ChoiceSet
基于样式和isMultiSelect
属性。 - 若要在群聊中使用动态类型头搜索,用户必须在应用清单中将范围添加到
groupchat
机器人安装范围,并将其安装到该特定群组聊天。 - 下拉列表中的选项数限制为 15 个。
架构属性
以下属性是用于启用类型头搜索的 Input.ChoiceSet
架构新增属性:
属性 | 类型 | 必需 | 说明 |
---|---|---|---|
style | 精简版 Expanded Filtered |
否 | 将筛选样式添加到静态类型支持的验证列表中。 |
choices.data | Data.Query | 否 | 通过从后端提取一组远程选项,在用户键入时启用动态类型。 |
值 | 字符串 | 否 | 必须选择的初始选项 (或选项集) 。 对于多选,请指定以逗号分隔的值字符串。 |
Data.Query 定义
属性 | 类型 | 必需 | 说明 |
---|---|---|---|
type | Data.Query | 是 | 指定它是 Data.Query 对象。 |
数据 | 字符串 | 是 | 指定动态提取的数据类型。 |
值 | 字符串 | 否 | 使用用户提供给 ChoiceSet 的输入填充对机器人的调用请求。 |
count | 数字 | 否 | 填充对机器人的调用请求,以指定必须返回的元素数。 如果用户想要发送其他数量,机器人将忽略它。 |
skip | 数字 | 否 | 填充对机器人的调用请求,以指示用户希望在列表中分页和继续前进。 |
示例
示例有效负载,其中包含静态和动态类型头搜索以及单选和多选选项,如下所示:
{
"type": "AdaptiveCard",
"body": [
{
"columns": [
{
"width": "1",
"items": [
{
"size": null,
"url": "https://urlp.asm.skype.com/v1/url/content?url=https%3a%2f%2fi.imgur.com%2fhdOYxT8.png",
"height": "auto",
"type": "Image"
}
],
"type": "Column"
},
{
"width": "2",
"items": [
{
"size": "extraLarge",
"text": "Game Purchase",
"weight": "bolder",
"wrap": true,
"type": "TextBlock"
}
],
"type": "Column"
}
],
"type": "ColumnSet"
},
{
"text": "Please fill out the below form to send a game purchase request.",
"wrap": true,
"type": "TextBlock"
},
{
"columns": [
{
"width": "auto",
"items": [
{
"text": "Game: ",
"wrap": true,
"height": "stretch",
"type": "TextBlock"
}
],
"type": "Column"
}
],
"type": "ColumnSet"
},
{
"columns": [
{
"width": "stretch",
"items": [
{
"choices": [
{
"title": "Call of Duty",
"value": "call_of_duty"
},
{
"title": "Death's Door",
"value": "deaths_door"
},
{
"title": "Grand Theft Auto V",
"value": "grand_theft"
},
{
"title": "Minecraft",
"value": "minecraft"
}
],
"style": "filtered",
"placeholder": "Search for a game",
"id": "choiceGameSingle",
"type": "Input.ChoiceSet"
}
],
"type": "Column"
}
],
"type": "ColumnSet"
},
{
"columns": [
{
"width": "auto",
"items": [
{
"text": "Multi-Game: ",
"wrap": true,
"height": "stretch",
"type": "TextBlock"
}
],
"type": "Column"
}
],
"type": "ColumnSet"
},
{
"columns": [
{
"width": "stretch",
"items": [
{
"choices": [
{
"title": "Static Option 1",
"value": "static_option_1"
},
{
"title": "Static Option 2",
"value": "static_option_2"
},
{
"title": "Static Option 3",
"value": "static_option_3"
}
],
"value": "Static_option_2",
"isMultiSelect": true,
"style": "filtered",
"choices.data": {
"type": "Data.Query",
"dataset": "xbox"
},
"id": "choiceGameMulti",
"type": "Input.ChoiceSet"
}
],
"type": "Column"
}
],
"type": "ColumnSet"
},
{
"columns": [
{
"width": "auto",
"items": [
{
"text": "Needed by: ",
"wrap": true,
"height": "stretch",
"type": "TextBlock"
}
],
"type": "Column"
},
{
"width": "stretch",
"items": [
{
"id": "choiceDate",
"type": "Input.Date"
}
],
"type": "Column"
}
],
"type": "ColumnSet"
},
{
"text": "Buy and download digital games and content directly from your Xbox console, Windows 10 PC, or at Xbox.com.",
"wrap": true,
"type": "TextBlock"
},
{
"text": "Earn points for what you already do on Xbox, then redeem your points on real rewards. Play more, get rewarded. Start earning today.",
"wrap": true,
"type": "TextBlock"
}
],
"actions": [
{
"data": {
"msteams": {
"type": "invoke",
"value": {
"type": "task/submit"
}
}
},
"title": "Request Purchase",
"type": "Action.Submit"
}
],
"$schema": "http://adaptivecards.io/schemas/adaptive-card.json",
"version": "1.2"
}
用于调用请求和响应的代码片段
调用请求
{
"name": "application/search",
"type": "invoke",
"value": {
"queryText": "fluentui",
"queryOptions": {
"skip": 0,
"top": 15
},
"dataset": "npm"
},
"locale": "en-US",
"localTimezone": "America/Los_Angeles",
// …. other fields
}
响应
protected override async Task<InvokeResponse> OnInvokeActivityAsync(ITurnContext<IInvokeActivity> turnContext, CancellationToken cancellationToken)
{
if (turnContext.Activity.Name == "application/search")
{
var packages = new[] {
new { title = "A very extensive set of extension methods", value = "FluentAssertions" },
new { title = "Fluent UI Library", value = "FluentUI" }};
var searchResponseData = new
{
type = "application/vnd.microsoft.search.searchResponse",
value = new
{
results = packages
}
};
var jsonString = JsonConvert.SerializeObject(searchResponseData);
JObject jsonData = JObject.Parse(jsonString);
return new InvokeResponse()
{
Status = 200,
Body = jsonData
};
}
return null;
}
代码示例
示例名称 | 说明 | .NET | Node.js | 清单 |
---|---|---|---|---|
自适应卡片上的 Typeahead 搜索控件 | 此示例演示如何在自适应卡片中使用静态和动态类型头搜索控件。 | View | View | View |
