Coreinfo v3.6
作者:Mark Russinovich
發佈時間:2022 年 9 月 29 日
下載 Coreinfo (531 KB)
Coreinfo 是命令列公用程式,會顯示邏輯處理器與實體處理器、NUMA 節點和其所在通訊端之間的對應,以及指派給每個邏輯處理器的快取。 它會使用 Windows 的 GetLogicalProcessorInformation 函式來取得這項資訊,並將它列印到畫面,代表與星號為 '*' 的邏輯處理器對應。 Coreinfo 有助於深入了解系統的處理器和快取拓撲。
將封存解壓縮到目錄,然後從主控台的 32 位元 Windows 版本的 Coreinfo
或 64 位元版本 Coreinfo64
目錄輸入,以執行 Coreinfo。
針對每個資源,它會顯示對應至指定資源之 OS 可見處理器的對應,其中 '*' 代表適用的處理器。 例如,在 4 核心系統上,具有核心 3 和 4 共用之對應之快取輸出中的一行。
使用量:coreinfo [-c][-f][-g][-l][-n][-s][-m][-v]
參數 | 描述 |
---|---|
-c | 傾印核心的資訊。 |
-f | 傾印核心功能資訊。 |
-g | 傾印群組的資訊。 |
-l | 傾印快取的資訊。 |
-n | 傾印 NUMA 節點的資訊。 |
-s | 傾印通訊端的資訊。 |
-m | 傾印 NUMA 存取成本。 |
-v | 僅傾印虛擬化相關功能,包括支援第二層位址轉譯。 |
(需要 Intel 系統上的系統權限)。 |
預設會選取 -v 以外的所有選項。
Coreinfo 輸出:
Coreinfo v3.03 - Dump information on system CPU and memory topology
Copyright (C) 2008-2011 Mark Russinovich
Sysinternals - www.sysinternals.com
Intel(R) Xeon(R) CPU W3520 @ 2.67GHz
Intel64 Family 6 Model 26 Stepping 5, GenuineIntel
EM64T * Supports 64-bit mode
VMX - Supports Intel hardware-assisted virtualization
SVM - Supports AMD hardware-assisted virtualization
HYPERVISOR * Hypervisor is present
HTT * Supports hyper-threading
SMX - Supports Intel trusted execution
SKINIT - Supports AMD SKINIT
EIST * Supports Enhanced Intel Speedstep
NX * Supports no-execute page protection
PAGE1GB - Supports 1GB large pages
PAE * Supports > 32-bit physical addresses
PAT * Supports Page Attribute Table
PSE * Supports 4-MB pages
PSE36 * Supports > 32-bit address 4-MB pages
PGE * Supports global bit in page tables
SS * Supports bus snooping for cache operations
VME * Supports Virtual-8086 mode
FPU * Implements i387 FP instructions
MMX * Supports MMX instruction set
MMXEXT - Implements AMD MMX extensions
3DNOW - Supports 3DNow! instructions
3DNOWEXT - Supports 3DNow! extension instructions
SSE * Supports Streaming SIMD Extensions
SSE2 * Supports Streaming SIMD Extensions 2
SSE3 * Supports Streaming SIMD Extensions 3
SSSE3 * Supports Supplemental SIMD Extensions 3
SSE4.1 * Supports Streaming SIMD Extensions 4.1
SSE4.2 * Supports Streaming SIMD Extensions 4.2
AES - Supports AES extensions
AVX - Supports AVX instruction extensions
FMA - Supports FMA extensions using YMM state
MSR * Implements RDMSR/WRMSR instructions
MTTR * Supports Mmeory Type Range Registers
XSAVE - Supports XSAVE/XRSTOR instructions
OSXSAVE - Supports XSETBV/XGETBV instructions
CMOV * Supports CMOVcc instruction
CLFSH * Supports CLFLUSH instruction
CX8 * Supports compare and exchange 8-byte instructions
CX16 * Supports CMPXCHG16B instruction
DCA - Supports prefetch from memory-mapped device
F16C - Supports half-precision instruction
FXSR * Supports FXSAVE/FXSTOR instructions
FFXSR - Supports optimized FXSAVE/FSRSTOR instruction
MONITOR - Supports MONITOR and MWAIT instructions
MOVBE - Supports MOVBE instruction
PCLULDQ - Supports PCLMULDQ instruction
POPCNT * Supports POPCNT instruction
SEP * Supports fast system call instructions
DE * Supports I/O breakpoints including CR4.DE
DTES64 - Can write history of 64-bit branch addresses
DS - Implements memory-resident debug buffer
DS-CPL - Supports Debug Store feature with CPL
PCID - Supports PCIDs and settable CR4.PCIDE
PDCM - Supports Performance Capabilities MSR
RDTSCP * Supports RDTSCP instruction
TSC * Supports RDTSC instruction
TSC-DEADLINE - Local APIC supports one-shot deadline timer
xTPR * Supports disabling task priority messages
ACPI * Implements MSR for power management
TM * Implements thermal monitor circuitry
TM2 * Implements Thermal Monitor 2 control
APIC * Implements software-accessible local APIC
x2APIC - Supports x2APIC
CNXT-ID - L1 data cache mode adaptive or BIOS
MCE * Supports Machine Check, INT18 and CR4.MCE
MCA * Implements Machine Check Architecture
PBE * Supports use of FERR#/PBE# pin
PSN - Implements 96-bit processor serial number
Logical to Physical Processor Map:
*--- Physical Processor 0
-*-- Physical Processor 1
--*- Physical Processor 2
---* Physical Processor 3
Logical Processor to Socket Map:
**** Socket 0
Logical Processor to NUMA Node Map:
**** NUMA Node 0
Logical Processor to Cache Map:
*--- Data Cache 0, Level 1, 32 KB, Assoc 8, LineSize 64
*--- Instruction Cache 0, Level 1, 32 KB, Assoc 4, LineSize 64
*--- Unified Cache 0, Level 2, 256 KB, Assoc 8, LineSize 64
-*-- Data Cache 1, Level 1, 32 KB, Assoc 8, LineSize 64
-*-- Instruction Cache 1, Level 1, 32 KB, Assoc 4, LineSize 64
-*-- Unified Cache 1, Level 2, 256 KB, Assoc 8, LineSize 64
--*- Data Cache 2, Level 1, 32 KB, Assoc 8, LineSize 64
--*- Instruction Cache 2, Level 1, 32 KB, Assoc 4, LineSize 64
--*- Unified Cache 2, Level 2, 256 KB, Assoc 8, LineSize 64
---* Data Cache 3, Level 1, 32 KB, Assoc 8, LineSize 64
---* Instruction Cache 3, Level 1, 32 KB, Assoc 4, LineSize 64
---* Unified Cache 3, Level 2, 256 KB, Assoc 8, LineSize 64
**** Unified Cache 4, Level 3, 8 MB, Assoc 16, LineSize 64
Logical Processor to Group Map:
**** Group 0
