Use ai.extract with PySpark

The ai.extract function extracts fields such as names, locations, or custom entities from each input row.

Note

Overview

The ai.extract function is available for Spark DataFrames. You must specify the name of an existing input column as a parameter, along with a list of entity types to extract from each row of text.

The function returns a new DataFrame, with a separate column for each specified entity type that contains extracted values for each input row.

Schema-driven extraction

aifunc.ExtractLabel supports JSON Schema definitions for structured extraction. Beyond basic types (string, number, integer, and boolean), you can use:

  • Enums: Constrain values to a fixed set (for example, "enum": ["midfielder", "striker", "defender"]).
  • Arrays: Define element schemas via items (for example, "type": "array", "items": {"type": "string"}).
  • Objects with properties: Specify nested fields with properties and their types.
  • Required fields: Mark mandatory fields with required to ensure they're always present in the output.
  • No extra fields: Set additionalProperties=false to prevent the model from returning fields outside the defined schema.
  • Nullable values: Express nullable types (for example, type=["string", "null"]) for optional data.

When used in PySpark, ai.extract runs as a distributed Spark transformation across Fabric Spark partitions.

Syntax

from synapse.ml.spark import aifunc

Note

The PySpark import path is from synapse.ml.spark import aifunc. For pandas, use from synapse.ml import aifunc.

df.ai.extract(labels=["entity1", "entity2", "entity3"], input_col="input")

Parameters

Name Description
labels
Required		 An array of strings that represents the set of entity types to extract from the text values in the input column.
input_col
Required		 A string that contains the name of an existing column with input text values to scan for the custom entities.
aifunc.ExtractLabel
Optional		 One or more label definitions describing the fields to extract. See ExtractLabel parameters.
error_col
Optional		 A string that contains the name of a new column to store any OpenAI errors that result from processing each input text row. If you don't set this parameter, a default name generates for the error column. If an input row has no errors, the value in this column is null.

ExtractLabel parameters

Name Description
label
Required		 A string that represents the entity to extract from the input text values.
description
Optional		 A string that adds extra context for the AI model. It can include requirements, context, or instructions for the AI to consider while performing the extraction.
max_items
Optional		 An int that specifies the maximum number of items to extract for this label.
type
Optional		 JSON schema type for the extracted value. Supported types for this class include string, number, integer, boolean, object, and array.
properties
Optional		 Additional JSON Schema properties for the type, such as items, properties, enum, required, and additionalProperties. Express nullable values with type=["string", "null"]. See Structured Outputs: Supported schemas.
raw_col
Optional		 A string that sets the column name for the raw LLM response. The raw response provides a list of dictionary pairs for every entity label, including "reason" and "extraction_text".

Returns

The function returns a Spark DataFrame with a new column for each specified entity type. The column or columns contain the entities extracted for each row of input text. If no match is found, the result is null.

The default return type is a list of strings for each label. When max_items isn't specified, multiple matches are returned as a list. If you specify a different type in the aifunc.ExtractLabel configuration (for example, type="integer"), the output is a list of values of that type. If you specify max_items=1, a single-element list is produced for that label. The element type of each list follows the schema you provide.

Example

# This code uses AI. Always review output for mistakes.

df = spark.createDataFrame([
        ("MJ Lee lives in Tucson, AZ, and works as a software engineer for Contoso.",),
        ("Kris Turner, a nurse at NYU Langone, is a resident of Jersey City, New Jersey.",)
    ], ["descriptions"])

df_entities = df.ai.extract(labels=["name", "profession", "city"], input_col="descriptions")
display(df_entities)

Output:

Screenshot showing a new data frame with the columns 'name', 'profession', and 'city', containing the data extracted from the original data frame.

Multimodal input

To extract fields from images, PDFs, or text files, set input_col_type="path". For setup, see Use multimodal input with AI Functions.

# This code uses AI. Always review output for mistakes.

extracted = custom_df.ai.extract(
    labels=[
        aifunc.ExtractLabel(
            "name",
            description="The full name of the candidate, first letter capitalized.",
            max_items=1,
        ),
        "companies_worked_for",
        aifunc.ExtractLabel(
            "year_of_experience",
            description="The total years of professional work experience the candidate has, excluding internships.",
            type="integer",
            max_items=1,
        ),
    ],
    input_col="file_path",
    input_col_type="path",
)
display(extracted)
