Tutorial: Add math problems to a math quiz WinForms app
In this series of four tutorials, you'll build a math quiz. The quiz contains four random math problems that a quiz taker tries to answer within a specified time.
Controls use C# or Visual Basic code. In this second tutorial, you make the quiz challenging by adding code for math problems that are based on random numbers. You also create a method that's named StartTheQuiz()
to fill in the problems.
In this second tutorial, you learn how to:
- Write code to create Random objects to use in math problems.
- Add an event handler for the start button.
- Write code to start the quiz.
Prerequisites
This tutorial builds on a previous tutorial, Create a math quiz WinForms app. If you haven't completed that tutorial, go through it first.
Create a random addition problem
In your Visual Studio project, select Windows Forms Designer.
Select the form, Form1.
On the menu bar, select View > Code. Form1.cs or Form1.vb appears, depending on the programming language that you're using, so that you can view the code behind the form.
Create a Random object by adding a
new
statement near the top of the code in Form1.cs or Form1.vb.
You can use new
statements like this one to create buttons, labels, panels, OpenFileDialogs, ColorDialogs, SoundPlayers, Randoms, and even forms. These items are called objects.
When you run your program, the form is started. The code behind it creates a Random object and names it randomizer.
Your quiz needs variables to store the random numbers that it creates for each problem. Before using variables, you declare them, which means listing their names and data types.
Add two integer variables to the form, and name them addend1 and addend2 in Form1.cs or Form1.vb.
Note
An integer variable is known as an int in C# or an Integer in Visual Basic. This kind of variable stores a positive or negative number from -2147483648 through 2147483647 and can store only whole numbers, not decimals.
You use similar syntax to add an integer variable as you did to add the Random object, as the following code shows.
Add a method that's named
StartTheQuiz()
Form1.cs or Form1.vb. This method uses the Random object's Next() method to generate random numbers for the labels.StartTheQuiz()
will eventually fill in all the problems and then start the timer, so add this information to the summary comment. The function should look like the following code./// <summary> /// Start the quiz by filling in all of the problems /// and starting the timer. /// </summary> public void StartTheQuiz() { // Fill in the addition problem. // Generate two random numbers to add. // Store the values in the variables 'addend1' and 'addend2'. addend1 = randomizer.Next(51); addend2 = randomizer.Next(51); // Convert the two randomly generated numbers // into strings so that they can be displayed // in the label controls. plusLeftLabel.Text = addend1.ToString(); plusRightLabel.Text = addend2.ToString(); // 'sum' is the name of the NumericUpDown control. // This step makes sure its value is zero before // adding any values to it. sum.Value = 0; }
When you use the Next()
method with a Random object, such as when you call randomizer.Next(51)
, you get a random number that's less than 51, or between 0 and 50. This code calls randomizer.Next(51)
so that the two random numbers add up to an answer that's between 0 and 100.
Take a closer look at these statements.
These statements set the Text properties of plusLeftLabel and plusRightLabel so that they display the two random numbers. Label controls display values in text format, and in programming, strings hold text. Each integer's ToString()
method converts the integer into text that a label can display.
Create random subtraction, multiplication, and division problems
The next step is to declare variables and provide random values for the other math problems.
Add integer variables for the remaining math problems to your form, after the addition problem variables. The code in Form1.cs or Form1.vb should look like the following sample.
public partial class Form1 : Form { // Create a Random object called randomizer // to generate random numbers. Random randomizer = new Random(); // These integer variables store the numbers // for the addition problem. int addend1; int addend2; // These integer variables store the numbers // for the subtraction problem. int minuend; int subtrahend; // These integer variables store the numbers // for the multiplication problem. int multiplicand; int multiplier; // These integer variables store the numbers // for the division problem. int dividend; int divisor;
Modify the
StartTheQuiz()
method in Form1.cs or Form1.vb by adding the following code, starting with the "Fill in the subtraction problem" comment./// <summary> /// Start the quiz by filling in all of the problem /// values and starting the timer. /// </summary> public void StartTheQuiz() { // Fill in the addition problem. // Generate two random numbers to add. // Store the values in the variables 'addend1' and 'addend2'. addend1 = randomizer.Next(51); addend2 = randomizer.Next(51); // Convert the two randomly generated numbers // into strings so that they can be displayed // in the label controls. plusLeftLabel.Text = addend1.ToString(); plusRightLabel.Text = addend2.ToString(); // 'sum' is the name of the NumericUpDown control. // This step makes sure its value is zero before // adding any values to it. sum.Value = 0; // Fill in the subtraction problem. minuend = randomizer.Next(1, 101); subtrahend = randomizer.Next(1, minuend); minusLeftLabel.Text = minuend.ToString(); minusRightLabel.Text = subtrahend.ToString(); difference.Value = 0; // Fill in the multiplication problem. multiplicand = randomizer.Next(2, 11); multiplier = randomizer.Next(2, 11); timesLeftLabel.Text = multiplicand.ToString(); timesRightLabel.Text = multiplier.ToString(); product.Value = 0; // Fill in the division problem. divisor = randomizer.Next(2, 11); int temporaryQuotient = randomizer.Next(2, 11); dividend = divisor * temporaryQuotient; dividedLeftLabel.Text = dividend.ToString(); dividedRightLabel.Text = divisor.ToString(); quotient.Value = 0;
This code uses the Next() method of the Random class a little differently from how the addition problem does. When you give the Next()
method two values, it picks a random number that's greater than or equal to the first value and less than the second one.
By using the Next()
method with two arguments, you can ensure the subtraction problem has a positive answer, the multiplication answer is at most 100, and the division answer isn't a fraction.
Add an event handler to the start button
In this section, you add code to start the quiz when the start button is selected. Code that runs in reaction to an event like a button selection is called an event handler.
In Windows Forms Designer, either double-click the Start the quiz button, or select it and then select Enter. The form's code appears, and a new method is visible.
These actions add a Click event handler to the start button. When a quiz taker selects this button, the app runs the code that you'll add to this new method.
Add the following two statements so that the event handler starts the quiz.
The first statement calls the new StartTheQuiz()
method. The second statement sets the Enabled property of the startButton control to false
so that the quiz taker can't select the button during a quiz.
Run your app
Save your code.
Run your app, and then select Start the quiz. Random math problems appear, as the following screenshot shows.
Next steps
Advance to the next tutorial to add a timer to your math quiz and check user answers.
