Sentinel AMA/CEF connector works but doesn't collect local syslog even with all facility log levels set to debug

David Broggy 5,681 Reputation points MVP
2023-04-29T16:50:37.3566667+00:00

Hi there,

I'd like to know if anyone has been successful in collecting LOCAL syslog data with the AMA/CEF connector.

My observations:

  • Default RedHat 8.6 VM running in Azure.
  • DCR enabled from Sentinel with all facilities set to debug. (VM is in scope)
  • Heartbeat logs are seen in log analytics
  • no 'local' syslog activity is being collected and sent to sentinel.
  • running the diagnostics script generates MOCK logs in CommonSecurityLog
  • (SELinux is disabled)

I'm hoping someone has seen this issue and can tell me how I can collect the local logs like ssh logins etc.

Microsoft Sentinel
Microsoft Sentinel
A scalable, cloud-native solution for security information event management and security orchestration automated response. Previously known as Azure Sentinel.
971 questions

3 answers

Sort by: Most helpful
Most helpful Newest Oldest
  1. Ankitkumar Patel 0 Reputation points Microsoft Employee
    2023-05-04T17:49:23.38+00:00

    Hello David,

    The issue is DCR you created from Microsoft Sentinel is only to collect data in CEF format.

    If you wish to collect data in Syslog format. you would have to create DCR for Syslog separately.

    Currently there is no connector for collecting Syslog via AMA and you would have to create DCR directly from the Monitor side

    You can follow the link below to get syslog format data to Workspace using AMA.

    Tutorial: Forward syslog data to a Log Analytics workspace by using the Azure Monitor agent

  2. Andrew Blumhardt 9,491 Reputation points Microsoft Employee
    2023-05-05T12:29:59.0066667+00:00

    My recommendation is to use the support request option found at the bottom of the Workspace menu.

    0 comments
  3. Peter Huxley 0 Reputation points
    2023-05-22T12:34:13.5466667+00:00

    It works, but is flaky not sure what the silver bullet is, but giggling with the DCR facilities to force it to update may/will eventually kick it into life, or wait a while.

    Key is seeing it create the syslog conf files in /etc/rsyslog.d

    05-azuremonitoragent-loadomuxsock.conf

    Azure Monitor Agent configuration: load rsyslog forwarding module.

    $ModLoad omuxsock

    10-azuremonitoragent.conf

    Azure Monitor Agent configuration: forward logs to azuremonitoragent

    $OMUxSockSocket /run/azuremonitoragent/default_syslog.socket

    template(name="AMA_RSYSLOG_TraditionalForwardFormat" type="string" string="<%PRI%>%TIMESTAMP% %HOSTNAME% %syslogtag%%msg:::sp-if-no-1st-sp%%msg%")

    $OMUxSockDefaultTemplate AMA_RSYSLOG_TraditionalForwardFormat

    Forwarding all events through Unix Domain Socket

    . :omuxsock:

    That's nicer than the * @@127.0.0.1:someport the previous agent used

    THEN you also need to check it's spun up the IPC/Domain socket(s)

    This one is working

    root@syslog01:/usr/local/bin# ls -l /run/azuremonitoragent/*

    srw-rw-rw- 1 syslog syslog 0 May 15 11:53 /run/azuremonitoragent/default_bond.socket

    srw-rw-rw- 1 syslog syslog 0 May 15 11:53 /run/azuremonitoragent/default_djson.socket

    srw-rw-rw- 1 syslog syslog 0 May 15 11:53 /run/azuremonitoragent/default_fluent.socket

    srw-rw-rw- 1 syslog syslog 0 May 15 11:53 /run/azuremonitoragent/default_influx.socket

    srw-rw-rw- 1 syslog syslog 0 May 15 11:53 /run/azuremonitoragent/default_json.socket

    -rw------- 1 syslog syslog 5 May 15 11:53 /run/azuremonitoragent/default.lock

    -rw-r--r-- 1 root root 5 May 15 11:53 /run/azuremonitoragent/default.pid

    -rw-r----- 1 syslog syslog 20 May 15 11:53 /run/azuremonitoragent/default.pidport

    srw-rw-rw- 1 syslog syslog 0 May 15 11:53 /run/azuremonitoragent/default_syslog.socket

    This one isn't

    root@isolatedsyslog01:~# ls -lrt /run/azuremonitoragent/*

    -rw-r--r-- 1 root root 4 May 22 10:21 /run/azuremonitoragent/default.pid

    -rw------- 1 syslog syslog 4 May 22 10:21 /run/azuremonitoragent/default.lock

    And that's why I'm here

    this is behind a proxy will ask a separate question but hope the above helps somebody

    0 comments
