Azure SQL Serverless DB

Question

Azure SQL Serverless DB

Dylan Miles 5

Hello -

I have migrated two SQL on-prem server to Azure SQL (Serverless) set to 1hr auto-pause primarily for cost saving. However after reviewing one of my DB are not pausing.

I have a DB A and a DB B on the same SQL Server

DB - A (This is production)

DB -B (This is development)

DB A in this case has not paused once, however DB B is pausing as expected, I have disconnected the application to prove this is not causing it from not auto-pausing and is looking very likely to be relating to the backups; however the policy is set the same for both.

This shows a backup almost every hour, if not more often - would this be preventing it from auto-pause; looking at the queries, I would say not?

SELECT *FROM sys.dm_database_backups ORDER BY backup_finish_date DESC;

I have run the following command to check what may be preventing it from auto-pausing and there is a EC2 connecting to it in a sleeping state that I am almost certain is AWS Services for the backup; this wouldn't stop auto-pause as it is in a sleeping state

SELECT session_id,

Upon Checking "Performance Overview" in the specific DB, I can see there is multiple task that is re-occurring queries every hour however these are using minimal to no CPU - could this be causing the issue, pink is also a long running query - could these be preventing auto-pause (long running being in our case 250ms to 2 seconds) - the backup retention policy is set to take a diff backup every 24hrs

User's image

Example 1: (Red)

(@backupTypeEquals nvarchar(1),@backupPathLike nvarchar(36))SELECT TOP 1  [backup_metadata_uuid],[database_guid],[physical_database_name],[time_zone],[first_lsn],[last_lsn],[checkpoint_lsn],[database_backup_lsn],[backup_start_date],[backup_finish_date],[backup_type],[backup_storage_redundancy],[database_version],[backup_size],[compressed_backup_size],[server_name],[is_damaged],[last_recovery_fork_guid],[differential_base_lsn],[differential_base_guid],[backup_path],[last_valid_restore_time],[compression_algorithm],[allocated_db_size_bytes],[allocated_data_size_bytes]  FROM [HIDDEN].[sys].[backup_metadata_store] WHERE (backup_type = @backupTypeEquals) AND (backup_path LIKE '%' + @backupPathLike + '%') ORDER BY backup_start_date DESC

Example 2: (Pink)

SELECT  [backup_metadata_uuid],[database_guid],[physical_database_name],[time_zone],[first_lsn],[last_lsn],[checkpoint_lsn],[database_backup_lsn],[backup_start_date],[backup_finish_date],[backup_type],[backup_storage_redundancy],[database_version],[backup_size],[compressed_backup_size],[server_name],[is_damaged],[last_recovery_fork_guid],[differential_base_lsn],[differential_base_guid],[backup_path],[last_valid_restore_time],[compression_algorithm],[allocated_db_size_bytes],[allocated_data_size_bytes]  FROM [HIDDEN].[sys].[backup_metadata_store]

Example 3: (Dark Blue)

(@backupTypeEquals nvarchar(1),@backupPathLike nvarchar(36),@backupFinishDateGreaterThan nvarchar(22))SELECT  [backup_metadata_uuid],[database_guid],[physical_database_name],[time_zone],[first_lsn],[last_lsn],[checkpoint_lsn],[database_backup_lsn],[backup_start_date],[backup_finish_date],[backup_type],[backup_storage_redundancy],[database_version],[backup_size],[compressed_backup_size],[server_name],[is_damaged],[last_recovery_fork_guid],[differential_base_lsn],[differential_base_guid],[backup_path],[last_valid_restore_time],[compression_algorithm],[allocated_db_size_bytes],[allocated_data_size_bytes]  FROM [HIDDEN].[sys].[backup_metadata_store] WHERE (backup_type = @backupTypeEquals) AND (backup_path LIKE '%' + @backupPathLike + '%') AND (backup_finish_date > @backupFinishDateGreaterThan)

Dylan Miles 5 Reputation points

2023-10-31T13:57:33.5966667+00:00

Query being run to check active activity as not showing above correctly:

SELECT session_id,
host_name,
program_name,
client_interface_name,
login_name,
status,
login_time,
last_request_start_time,
last_request_end_time
FROM sys.dm_exec_sessions AS s
INNER JOIN sys.dm_resource_governor_workload_groups AS wg
ON s.group_id = wg.group_id
WHERE s.session_id <> @@SPID
AND
(
(
wg.name like 'UserPrimaryGroup.DB%'
AND
TRY_CAST(RIGHT(wg.name, LEN(wg.name) - LEN('UserPrimaryGroup.DB') - 2) AS int) = DB_ID()
)
OR
wg.name = 'DACGroup'
);

Reference: https://learn.microsoft.com/en-us/answers/questions/867440/how-did-my-azure-bill-get-this-high

1 answer

Your answer

Dylan Miles 5 Reputation points

2023-10-31T13:57:33.5966667+00:00

Query being run to check active activity as not showing above correctly:

SELECT session_id,
host_name,
program_name,
client_interface_name,
login_name,
status,
login_time,
last_request_start_time,
last_request_end_time
FROM sys.dm_exec_sessions AS s
INNER JOIN sys.dm_resource_governor_workload_groups AS wg
ON s.group_id = wg.group_id
WHERE s.session_id <> @@SPID
AND
(
(
wg.name like 'UserPrimaryGroup.DB%'
AND
TRY_CAST(RIGHT(wg.name, LEN(wg.name) - LEN('UserPrimaryGroup.DB') - 2) AS int) = DB_ID()
)
OR
wg.name = 'DACGroup'
);

Reference: https://learn.microsoft.com/en-us/answers/questions/867440/how-did-my-azure-bill-get-this-high

Answer 1

Auto-pausing is triggered if all of the following conditions are true for the duration of the auto-pause delay:

Number of sessions = 0
CPU = 0 for user workload running in the user resource pool

The following features do not support auto-pausing, but do support auto-scaling. If any of the following features are used, then auto-pausing must be disabled and the database will remain online regardless of the duration of database inactivity:

Geo-replication (active geo-replication and auto-failover groups).
Long-term backup retention (LTR).
The sync database used in SQL Data Sync. Unlike sync databases, hub and member databases support auto-pausing.
DNS alias created for the logical server containing a serverless database.
Elastic Jobs (preview), Auto-pause enabled serverless database is not supported as a Job Database. Serverless databases targeted by elastic jobs do support auto-pausing, and will be resumed by job connections.

Auto-pausing is temporarily prevented during the deployment of some service updates which require the database be online. In such cases, auto-pausing becomes allowed again once the service update completes.

If auto-pausing is enabled, but a database does not auto-pause after the delay period, and the features listed above are not used, the application or user sessions may be preventing auto-pausing. To see if there are any application or user sessions currently connected to the database, connect to the database using any client tool, and execute the following query:

SELECT session_id,
       host_name,
       program_name,
       client_interface_name,
       login_name,
       status,
       login_time,
       last_request_start_time,
       last_request_end_time
FROM sys.dm_exec_sessions AS s
INNER JOIN sys.dm_resource_governor_workload_groups AS wg
ON s.group_id = wg.group_id
WHERE s.session_id <> @@SPID
      AND
      (
      (
      wg.name like 'UserPrimaryGroup.DB%'
      AND
      TRY_CAST(RIGHT(wg.name, LEN(wg.name) - LEN('UserPrimaryGroup.DB') - 2) AS int) = DB_ID()
      )
      OR
      wg.name = 'DACGroup'
      );

After running the query, make sure to disconnect from the database. Otherwise, the open session used by the query will prevent auto-pausing.

If the result set is non-empty, it indicates that there are sessions currently preventing auto-pausing.

If the result set is empty, it is still possible that sessions were open, possibly for a short time, at some point earlier during the auto-pause delay period. To see if such activity has occurred during the delay period, you can use Azure SQL Auditing and examine audit data for the relevant period.

Reference: https://learn.microsoft.com/en-us/azure/azure-sql/database/serverless-tier-overview?view=azuresql&tabs=general-purpose

GeethaThatipatri-MSFT 29,542 Reputation points Microsoft Employee Moderator

2023-11-01T14:32:00.72+00:00

@Dylan Miles Greetings, Looks like you have done a thorough investigation of the issue, for further investigation I would suggest raising a support case.

Regards

Geetha
Andy Felton 0 Reputation points

2023-11-01T18:11:37.7766667+00:00

@Dylan Miles I'm seeing exactly the issue with one of my DBs created yesterday - if you get anywhere would be great to know what the issue was.

Thanks

Andy
GK87 191 Reputation points

2024-01-25T10:57:13.2+00:00

@Dylan Miles I was doing the exact same investigation as you since I'm seeing the same issue with a serverless database utilizing some SQL Instance CPU and the same type of queries every hour during some hours of the day. This prevents pausing from happening it seems. That's how I ended up here. Did you find a solution/cause to this?
Erland Sommarskog 121.4K Reputation points MVP Volunteer Moderator

2024-01-25T22:00:50.58+00:00

What about checking Query Store for the intervals where you expect the server to be stopped? That can show you which queries that has been executed in that interval.
