Data transformations in Container insights
This article describes how to implement data transformations in Container insights. Transformations in Azure Monitor allow you to modify or filter data before it's ingested in your Log Analytics workspace. They allow you to perform such actions as filtering out data collected from your cluster to save costs or processing incoming data to assist in your data queries.
Data Collection Rules (DCRs)
Transformations are implemented in data collection rules (DCRs) which are used to configure data collection in Azure Monitor. When you onboard Container insights for a cluster, a DCR is created for it with the name MSCI-<cluster-region>-<\cluster-name>. You can view this DCR from Data Collection Rules in the Monitor menu in the Azure portal. To create a transformation, you must either modify this DCR, or onboard your cluster with a custom DCR that includes your transformation.
The following table describes the different methods to edit the DCR, while the rest of this article provides details of the edits that you need to perform to transform Container insights data.
| Method | Description |
|---|---|
| New cluster | Use an existing ARM template to onboard an AKS cluster to Container insights. Modify the dataFlows section of the DCR in that template to include a transformation, similar to one of the samples below. |
| Existing DCR | After a cluster has been onboarded to Container insights, edit its DCR to include a transformation using the process in Editing Data Collection Rules. |
Data sources
The dataSources section of the DCR defines the different types of incoming data that the DCR will process. For Container insights, this includes the ContainerInsights extension, which includes one or more predefined streams starting with the prefix Microsoft-.
The list of Container insights streams in the DCR depends on the Cost preset that you selected for the cluster. If you collect all tables, the DCR will use the Microsoft-ContainerInsights-Group-Default stream, which is a group stream that includes all of the streams listed in Stream values. You must change this to individual streams if you're going to use a transformation. Any other cost preset settings will already use individual streams.
The snippet below shows the Microsoft-ContainerInsights-Group-Default stream. See the Sample DCRs for a sample of individual streams.
"dataSources": {
"extensions": [
{
"name": "ContainerInsightsExtension",
"extensionName": "ContainerInsights",
"extensionSettings": { },
"streams": [
"Microsoft-ContainerInsights-Group-Default"
]
}
]
}
Data flows
The dataFlows section of the DCR matches streams with destinations. The streams that don't require a transformation can be grouped together in a single entry that includes only the workspace destination. Create a separate entry for streams that require a transformation that includes the workspace destination and the transformKql property.
The snippet below shows the dataFlows section for a single stream with a transformation. See the Sample DCRs for multiple data flows in a single DCR.
"dataFlows": [
{
"streams": [
"Microsoft-ContainerLogV2"
],
"destinations": [
"ciworkspace"
],
"transformKql": "source | where PodNamespace == 'kube-system'"
}
]
Sample DCRs
The following samples show DCRs for Container insights using transformations. Use these samples as a starting point and customize then as required to meet your particular requirements.
Filter for a particular namespace
This sample uses the log query source | where PodNamespace == 'kube-system' to collect data for a single namespace in ContainerLogsV2. You can replace kube-system in this query with another namespace or replace the where clause with another filter to match the particular data you want to collect. The other streams are grouped into a separate data flow and have no transformation applied.
{
"properties": {
"dataSources": {
"syslog": [],
"extensions": [
{
"name": "ContainerInsightsExtension",
"extensionName": "ContainerInsights",
"extensionSettings": { },
"streams": [
"Microsoft-ContainerLog",
"Microsoft-ContainerLogV2",
"Microsoft-KubeEvents",
"Microsoft-KubePodInventory",
"Microsoft-KubeNodeInventory",
"Microsoft-KubePVInventory",
"Microsoft-KubeServices",
"Microsoft-KubeMonAgentEvents",
"Microsoft-InsightsMetrics",
"Microsoft-ContainerInventory",
"Microsoft-ContainerNodeInventory",
"Microsoft-Perf"
]
}
]
},
"destinations": {
"logAnalytics": [
{
"workspaceResourceId": "/subscriptions/00000000-0000-0000-0000-000000000000/resourcegroups/my-resource-group/providers/microsoft.operationalinsights/workspaces/my-workspace",
"name": "ciworkspace"
}
]
},
"dataFlows": [
{
"streams": [
"Microsoft-ContainerLog",
"Microsoft-KubeEvents",
"Microsoft-KubePodInventory",
"Microsoft-KubeNodeInventory",
"Microsoft-KubePVInventory",
"Microsoft-KubeServices",
"Microsoft-KubeMonAgentEvents",
"Microsoft-InsightsMetrics",
"Microsoft-ContainerNodeInventory",
"Microsoft-Perf"
],
"destinations": [
"ciworkspace"
]
},
{
"streams": [
"Microsoft-ContainerLogV2"
],
"destinations": [
"ciworkspace"
],
"transformKql": "source | where PodNamespace == 'kube-system'"
}
]
}
}
Add a column to a table
This sample uses the log query source | extend new_CF = ContainerName to send data to a custom column added to the ContainerLogV2 table. This transformation requires that you add the custom column to the table using the process described in Add or delete a custom column. The other streams are grouped into a separate data flow and have no transformation applied.
{
"properties": {
"dataSources": {
"syslog": [],
"extensions": [
{
"extensionName": "ContainerInsights",
"extensionSettings": { },
"name": "ContainerInsightsExtension",
"streams": [
"Microsoft-ContainerLog",
"Microsoft-ContainerLogV2",
"Microsoft-KubeEvents",
"Microsoft-KubePodInventory",
"Microsoft-KubeNodeInventory",
"Microsoft-KubePVInventory",
"Microsoft-KubeServices",
"Microsoft-KubeMonAgentEvents",
"Microsoft-InsightsMetrics",
"Microsoft-ContainerInventory",
"Microsoft-ContainerNodeInventory",
"Microsoft-Perf"
]
}
]
},
"destinations": {
"logAnalytics": [
{
"workspaceResourceId": "/subscriptions/00000000-0000-0000-0000-000000000000/resourcegroups/my-resource-group/providers/microsoft.operationalinsights/workspaces/my-workspace",
"name": "ciworkspace"
}
]
},
"dataFlows": [
{
"streams": [
"Microsoft-ContainerLog",
"Microsoft-KubeEvents",
"Microsoft-KubePodInventory",
"Microsoft-KubeNodeInventory",
"Microsoft-KubePVInventory",
"Microsoft-KubeServices",
"Microsoft-KubeMonAgentEvents",
"Microsoft-InsightsMetrics",
"Microsoft-ContainerNodeInventory",
"Microsoft-Perf"
],
"destinations": [
"ciworkspace"
]
},
{
"streams": [
"Microsoft-ContainerLogV2"
],
"destinations": [
"ciworkspace"
],
"transformKql": "source\n | extend new_CF = ContainerName"
}
]
}
}
Next steps
- Read more about transformations and data collection rules in Azure Monitor.
