Enable tool search in a toolbox (preview)

Important

Items marked (preview) in this article are currently in public preview. This preview is provided without a service-level agreement, and we don't recommend it for production workloads. Certain features might not be supported or might have constrained capabilities. For more information, see Supplemental Terms of Use for Microsoft Azure Previews.

When a toolbox contains many tools, passing all tool definitions to the model on every turn creates three compounding problems: token costs grow with every tool added to the context, the context window fills with definitions the current task doesn't need, and the model picks the wrong tools from an overcrowded list. Tool search solves this by replacing the full tool list with two focused meta-tools—keeping cost flat regardless of toolbox size.

When tool search is enabled, the model receives two built-in meta-tools: tool_search, which it calls with a natural-language description of the capability it needs, and call_tool, which it uses to invoke any discovered tool by name. Foundry evaluates tool_search queries against the full set of tools in the toolbox and returns only the ones that match, keeping the active context focused and relevant.

Use tool search when:

  • Your toolbox has more than 10–15 tools and you want to avoid context bloat.
  • Different agent tasks need different subsets of tools, and you want the model to pick the right subset dynamically.

Prerequisites

How tool search works

When you include {"type": "toolbox_search_preview"} in a toolbox, all tools in the toolbox are hidden from the initial tools/list response. Instead, Foundry injects two meta-tools:

  • tool_search — the model calls this with a natural-language description of the capability it needs. Foundry evaluates the query and returns the matching tool definitions.
  • call_tool — the model uses this to invoke any discovered tool by name.

The model doesn't browse a full tool list—it describes intent, discovers the right tools, and calls them.

The tool_search function accepts the following parameters:

Parameter Type Required Description
query string Yes Natural-language description of the capability or task you need a tool for.
limit integer No Maximum number of tools to return. Defaults to a platform value when omitted.

The model can call tool_search as many times as needed during a single turn. Each call returns only the tools that match the query, so the active context stays focused on what's relevant to the current step. Tools returned by tool_search remain callable for the rest of the turn without repeated searching.

Note

The toolbox_search_preview entry is a configuration directive that activates tool search. It doesn't appear in tools/list itself and doesn't count toward the unnamed-tool-per-type limit.

Add {"type": "toolbox_search_preview"} to your toolbox version's tools list. All other tools in the toolbox are available through tool search — they aren't exposed in the initial tool list the model sees.

import os
from azure.identity import DefaultAzureCredential
from azure.ai.projects import AIProjectClient

client = AIProjectClient(
    endpoint=os.environ["FOUNDRY_PROJECT_ENDPOINT"],
    credential=DefaultAzureCredential(),
)

# {"type": "toolbox_search_preview"} enables tool search — other tools are discovered on demand via tool_search
toolbox_version = client.beta.toolboxes.create_version(
    name="my-toolbox",
    description="Large toolbox with tool search enabled",
    tools=[
        {"type": "toolbox_search_preview"},
        {
            "type": "mcp",
            "server_label": "github",
            "server_url": "https://api.githubcopilot.com/mcp",
            "require_approval": "never",
            "project_connection_id": "github-mcp-conn",
        },
        {
            "type": "mcp",
            "server_label": "calendar",
            "server_url": "https://your-calendar-mcp.example.com",
            "require_approval": "never",
            "description": "Read and write calendar events",
        },
    ],
)
print(f"Created toolbox `{toolbox_version.name}` (version {toolbox_version.version})")

POST {project_endpoint}/toolboxes/my-toolbox/versions?api-version=v1
Authorization: Bearer {token}
Content-Type: application/json

{
  "description": "Large toolbox with tool search enabled",
  "tools": [
    {
      "type": "toolbox_search_preview"
    },
    {
      "type": "mcp",
      "server_label": "github",
      "server_url": "https://api.githubcopilot.com/mcp",
      "require_approval": "never",
      "project_connection_id": "github-mcp-conn"
    },
    {
      "type": "mcp",
      "server_label": "calendar",
      "server_url": "https://your-calendar-mcp.example.com",
      "require_approval": "never"
    }
  ]
}

Note

Use token scope https://ai.azure.com/.default when getting the bearer token.

Verify tool search is active

Use the version-specific endpoint to confirm that tool_search appears in tools/list and that no other toolbox tools are exposed in the initial listing.

Install the MCP client SDK if you haven't already:

pip install mcp

import asyncio
from azure.identity import DefaultAzureCredential
from mcp.client.streamable_http import streamablehttp_client
from mcp import ClientSession

url = "https://<account>.services.ai.azure.com/api/projects/<proj>/toolboxes/<name>/versions/<version>/mcp?api-version=v1"

token = DefaultAzureCredential().get_token("https://ai.azure.com/.default").token
headers = {
    "Authorization": f"Bearer {token}",
    "Foundry-Features": "Toolboxes=V1Preview",
}

async def verify_toolbox():
    async with streamablehttp_client(url, headers=headers) as (read, write, _):
        async with ClientSession(read, write) as session:
            await session.initialize()

            # List available tools -- only tool_search should appear initially
            tools_result = await session.list_tools()
            print(f"Tools found: {len(tools_result.tools)}")
            for tool in tools_result.tools:
                print(f"  - {tool.name}: {(tool.description or '')[:80]}")

            # Confirm tool_search is present
            names = [t.name for t in tools_result.tools]
            assert "tool_search" in names, "tool_search not found -- check toolbox_search_preview config"

asyncio.run(verify_toolbox())

Use the version-specific endpoint (/versions/{version}/mcp) to validate before promoting.

1. Initialize the MCP session:

POST {project_endpoint}/toolboxes/{toolbox_name}/versions/{version}/mcp?api-version=v1
Authorization: Bearer {token}
Content-Type: application/json
Foundry-Features: Toolboxes=V1Preview

{"jsonrpc":"2.0","id":1,"method":"initialize","params":{"protocolVersion":"2025-03-26","capabilities":{},"clientInfo":{"name":"test","version":"1.0"}}}

2. Send the initialized notification:

POST {project_endpoint}/toolboxes/{toolbox_name}/versions/{version}/mcp?api-version=v1
Authorization: Bearer {token}
Content-Type: application/json
Foundry-Features: Toolboxes=V1Preview

{"jsonrpc":"2.0","method":"notifications/initialized"}

3. List available tools:

POST {project_endpoint}/toolboxes/{toolbox_name}/versions/{version}/mcp?api-version=v1
Authorization: Bearer {token}
Content-Type: application/json
Foundry-Features: Toolboxes=V1Preview

{"jsonrpc":"2.0","id":2,"method":"tools/list","params":{}}

In result.tools, tool_search should be present and all other toolbox tools should be absent from the initial listing.

Fine-tune tool discovery

Tool search works without additional configuration. For predictable usage patterns, you can tune how specific tools are surfaced and indexed.

Pin critical tools

Use pin to make a specific tool always appear in tools/list alongside tool_search and call_tool. Pinned tools are callable immediately without a search round-trip. To pin every tool in an MCP server or built-in tool entry, use "*" as the key.

tools=[
    {"type": "toolbox_search_preview"},
    {
        "type": "mcp",
        "server_label": "analytics",
        "server_url": "https://db-mcp.internal/sse",
        "tool_configs": {
            "execute_query": {"pin": True},  # always visible — no search needed
        },
    },
]

{
  "tools": [
    { "type": "toolbox_search_preview" },
    {
      "type": "mcp",
      "server_label": "analytics",
      "server_url": "https://db-mcp.internal/sse",
      "tool_configs": {
        "execute_query": { "pin": true }
      }
    }
  ]
}

To pin every tool in an entry, use "*" as the key:

{
    "type": "mcp",
    "server_label": "analytics",
    "server_url": "https://db-mcp.internal/sse",
    "tool_configs": {
        "*": {"pin": True},  # every tool in this server is always visible
    },
}

{
  "type": "mcp",
  "server_label": "analytics",
  "server_url": "https://db-mcp.internal/sse",
  "tool_configs": {
    "*": { "pin": true }
  }
}

Add search keywords

If a tool's MCP description doesn't match the vocabulary users naturally use, add keywords with additional_search_text. The extra text is used only for search ranking—it's never exposed to the model in the tool schema.

{
    "type": "mcp",
    "server_label": "analytics",
    "server_url": "https://db-mcp.internal/sse",
    "tool_configs": {
        "execute_query": {
            "pin": True,
            "additional_search_text": "SQL database analytics reporting dashboard queries",
        },
        "list_tables": {
            "additional_search_text": "schema columns metadata table structure discover",
        },
    },
}

{
  "type": "mcp",
  "server_label": "analytics",
  "server_url": "https://db-mcp.internal/sse",
  "tool_configs": {
    "execute_query": {
      "pin": true,
      "additional_search_text": "SQL database analytics reporting dashboard queries"
    },
    "list_tables": {
      "additional_search_text": "schema columns metadata table structure discover"
    }
  }
}

Auto-pinning

Foundry automatically tracks which tools each user calls most frequently and surfaces them directly in tools/list—no configuration required. After a short warmup period, frequently used tools appear without a search round-trip. The hot set is per-user and updates as usage patterns shift; stale entries age out automatically.

Auto-pinning composes with explicit pin and additional_search_text configuration. Pin the critical tools you know about upfront, add keywords for tools with ambiguous names, and let auto-pinning handle the long tail as usage patterns emerge.

Configuration reference

toolbox_search_preview

Field Type Required Description
type "toolbox_search_preview" Yes Activates tool search for the toolbox.

Include {"type": "toolbox_search_preview"} in your toolbox's tools list to enable tool search. All other configuration fields are optional.

tool_configs (per-tool)

Set tool_configs on an individual MCP tool entry to control how specific tools behave within the search context. Use an exact tool name as the key to configure a specific tool, or "*" to apply the configuration to all tools in that entry.

Field Type Description
pin boolean When true, the tool appears directly in tools/list alongside tool_search and call_tool. The model can call it without searching first.
additional_search_text string Extra keywords added to the tool's search index entry. Used for search ranking only—never visible to the model in the tool schema.

Considerations

  • All toolbox tools are hidden from the initial listing. When toolbox_search_preview is in a toolbox, no other toolbox tools appear in tools/list. The model discovers them only through tool_search. Tools added directly to an agent outside the toolbox are unaffected and remain visible.
  • Tool descriptions drive match quality. Foundry uses tool names and descriptions to evaluate search queries. A tool without a description, or with a vague one, is unlikely to be returned even for relevant queries. Write descriptions that describe what the tool does and the kinds of tasks it handles.
  • tool_search doesn't count toward tool limits. It's injected by the platform and doesn't consume the unnamed-tool-per-type slot.
  • Multiple searches per turn are supported. The model can call tool_search more than once in a single turn if different steps need different capabilities.
  • Returned tools persist for the turn. Once a tool is returned by tool_search, the model can call it multiple times without re-searching.
  • Pinned tools always appear in tools/list. Tools with "pin": True in tool_configs appear alongside tool_search and call_tool on every turn, regardless of search queries.
  • Auto-pinning surfaces frequently used tools automatically. Foundry tracks per-user tool call frequency and promotes the most-called tools to tools/list after a short warmup period. The hot set is per-user and updates as usage patterns shift.
  • OAuth consent may be required. If any tool in the toolbox connects to an OAuth-based MCP server, the first call returns a CONSENT_REQUIRED error (code -32007) with a consent URL in the response. Open that URL in a browser, complete the OAuth flow, then retry. Subsequent calls succeed without re-prompting. See Troubleshoot toolbox errors for handling this error.

Best practices

  • Add a description to every tool. Tool search uses descriptions to match tools to queries. A missing or vague description causes poor discovery.
  • Use tool search for large toolboxes. This is the most effective configuration when you have 10 or more tools.
  • Use tool search together with toolbox versioning. Test your configuration on a version-specific endpoint before promoting it to default.
  • Mention tool search in the system prompt. Guide the model to call tool_search before concluding that a capability is unavailable. For example: "If you need a tool that isn't in your current list, call tool_search with a description of what you need before responding that you can't help."
  • Pin always-needed tools. Use "pin": True in tool_configs for tools called on nearly every turn to skip the search round-trip.
  • Use additional_search_text when descriptions are ambiguous. If your team uses different vocabulary than the MCP server's tool descriptions, add keywords to improve search precision without modifying the server.

Troubleshoot

Symptom Likely cause Fix
tool_search is missing from tools/list toolbox_search_preview wasn't included in the toolbox version, or you're connected to a version that predates the change. Add {"type": "toolbox_search_preview"} to the tools list and create a new version. Confirm you're using the updated version's endpoint.
tool_search returns no results for a query Tools in the toolbox have no description or descriptions don't relate to the query. Add or improve descriptions on the tools in the toolbox. Descriptions should explain what the tool does and the kinds of tasks it handles.
A toolbox tool appears in the initial tools/list The tool was added directly to the agent instead of, or in addition to, the toolbox definition. Remove the tool from the agent's direct tool list and rely on the toolbox. Tools added directly to an agent are always visible, regardless of tool search.
The model never calls tool_search The model doesn't know tool_search can retrieve additional tools. Add an instruction in the system prompt telling the model to call tool_search when a needed capability isn't in its current tool list.
tool_search is called but the tool returned fails to execute The underlying tool's connection or configuration is invalid. Verify the project_connection_id and other fields on the returned tool. Test the tool directly through the toolbox MCP endpoint without tool search enabled.
