Card actions

  • Article
  • 9 minutes to read

Cards used by bots and message extensions in Teams support the following activity CardAction types:

Note

The CardAction actions differ from potentialActions for connector cards for Microsoft 365 Groups when used from connectors.

Type Action
openUrl Opens a URL in the default browser.
messageBack Sends a message and payload to the bot from the user who selected the button or tapped the card. Sends a separate message to the chat stream.
imBack Sends a message to the bot from the user who selected the button or tapped the card. This message from user to bot is visible to all conversation participants.
invoke Sends a message and payload to the bot from the user who selected the button or tapped the card. This message isn't visible.
signin Initiates OAuth flow, allowing bots to connect with secure services.

Note

  • Teams does not support CardAction types not listed in the previous table.
  • Teams does not support the potentialActions property.
  • Card actions are different than suggested actions in Bot Framework or Azure Bot Service.
  • If you are using a card action as part of a message extension, the actions do not work until the card is submitted to the channel. The actions do not work while the card is in the compose message box.

Action type openUrl

openUrl action type specifies a URL to launch in the default browser.

Note

  • Your bot doesn't receive any notice on which button was selected.
  • Machine names with numbers aren't supported in URL.

With openUrl, you can create an action with the following properties:

Property Description
title Appears as the button label.
value This field must contain a full and properly formed URL.

The following code shows an example of openUrl action type in JSON:

{
    "type": "openUrl",
    "title": "Tabs in Teams",
    "value": "https://msdn.microsoft.com/microsoft-teams/tabs"
}

Action type messageBack

With messageBack, you can create a fully customized action with the following properties:

Property Description
title Appears as the button label.
displayText Optional. Used by the user in the chat stream when the action is performed. This text isn't sent to your bot.
value Sent to your bot when the action is performed. You can encode context for the action, such as unique identifiers or a JSON object.
text Sent to your bot when the action is performed. Use this property to simplify bot development. Your code can check a single top-level property to dispatch bot logic.

The flexibility of messageBack means that your code can't leave a visible user message in the history simply by not using displayText.

The following code shows an example of messageBack action type in JSON:

{
  "buttons": [
    {
    "type": "messageBack",
    "title": "My MessageBack button",
    "displayText": "I clicked this button",
    "text": "User just clicked the MessageBack button",
    "value": "{\"property\": \"propertyValue\" }"
    }
  ]
}

The value property can be either a serialized JSON string or a JSON object.

Inbound message example

replyToId contains the ID of the message that the card action came from. Use it if you want to update the message.

The following code shows an example of inbound message:

{
   "text":"User just clicked the MessageBack button",
   "value":{
      "property":"propertyValue"
   },
   "type":"message",
   "timestamp":"2017-06-22T22:38:47.407Z",
   "id":"f:5261769396935243054",
   "channelId":"msteams",
   "serviceUrl":"https://smba.trafficmanager.net/amer-client-ss.msg/",
   "from":{
      "id":"29:102jd210jd010icsoaeclaejcoa9ue09u",
      "name":"John Smith"
   },
   "conversation":{
      "id":"19:malejcou081i20ojmlcau0@thread.skype;messageid=1498171086622"
   },
   "recipient":{
      "id":"28:76096e45-119f-4736-859c-6dfff54395f7",
      "name":"MyBot"
   },
   "entities":[
      {
        "locale": "en-US",
        "country": "US",
        "platform": "Windows",
        "timezone": "America/Los_Angeles",
        "type": "clientInfo"
      }
   ],
   "channelData":{
      "channel":{
         "id":"19:malejcou081i20ojmlcau0@thread.skype"
      },
      "team":{
         "id":"19:12d021jdoijsaeoaue0u@thread.skype"
      },
      "tenant":{
         "id":"bec8e231-67ad-484e-87f4-3e5438390a77"
      }
   },
        "replyToId": "1575667808184",
}

Action type imBack

The imBack action triggers a return message to your bot, as if the user typed it in a normal chat message. Your user and all other users in a channel can see the button response.

With imBack, you can create an action with the following properties:

Property Description
title Appears as the button label.
value This field must contain the text string used in the chat and therefore sent back to the bot. This is the message text you process in your bot to perform the desired logic.

Note

The value field is a simple string. There is no support for formatting or hidden characters.

The following code shows an example of imBack action type in JSON:

{
    "type": "imBack",
    "title": "More",
    "value": "Show me more"
}

Action type invoke

The invoke action is used for invoking task modules.

The invoke action contains three properties, type, title, and value.

With invoke, you can create an action with the following properties:

Property Description
title Appears as the button label.
value This property can contain a string, a stringified JSON object, or a JSON object.

The following code shows an example of invoke action type in JSON:

{
    "type": "invoke",
    "title": "Option 1",
    "value": {
        "option": "opt1"
    }
}

When a user selects the button, your bot receives the value object with some additional information.

Note

The activity type is invoke instead of message that is activity.Type == "invoke".

Example of incoming invoke message

The top-level replyToId property contains the ID of the message that the card action came from. Use it if you want to update the message.

The following code shows an example of incoming invoke message:

{
    "type": "invoke",
    "value": {
        "option": "opt1"
    },
    "timestamp": "2017-02-10T04:11:19.614Z",
    "localTimestamp": "2017-02-09T21:11:19.614-07:00",
    "id": "f:6894910862892785420",
    "channelId": "msteams",
    "serviceUrl": "https://smba.trafficmanager.net/amer-client-ss.msg/",
    "from": {
        "id": "29:1Eniglq0-uVL83xNB9GU6w_G5a4SZF0gcJLprZzhtEbel21G_5h-
    NgoprRw45mP0AXUIZVeqrsIHSYV4ntgfVJQ",
        "name": "John Doe"
    },
    "conversation": {
        "id": "19:97b1ec61-45bf-453c-9059-6e8984e0cef4_8d88f59b-ae61-4300-bec0-caace7d28446@unq.gbl.spaces"
    },
    "recipient": {
        "id": "28:8d88f59b-ae61-4300-bec0-caace7d28446",
        "name": "MyBot"
    },
    "entities": [
        {
            "locale": "en-US",
            "country": "US",
            "platform": "Web",
            "type": "clientInfo"
        }
    ],
    "channelData": {
        "channel": {
            "id": "19:dc5ba12695be4eb7bf457cad6b4709eb@thread.skype"
        },
        "team": {
            "id": "19:712c61d0ef384e5fa681ba90ca943398@thread.skype"
        },
        "tenant": {
            "id": "72f988bf-86f1-41af-91ab-2d7cd011db47"
        }
    },
    "replyToId": "1575667808184"
}

Action type sign-in

signin action type initiates an OAuth flow that permits bots to connect with secure services. For more information, see authentication flow in bots.

Teams also supports Adaptive Cards actions that are only used by Adaptive Cards.

The following code shows an example of signin action type in JSON:

{
"type": "signin",
"title": "Click me for signin",
"value": "https://signin.com"
}

Adaptive Cards actions

Adaptive Cards support four action types:

You can also modify the Adaptive Card Action.Submit payload to support existing Bot Framework actions using an msteams property in the data object of Action.Submit. The next section provides details on how to use existing Bot Framework actions with Adaptive Cards.

Note

  • Adding msteams to data with a Bot Framework action does not work with an Adaptive Card task module.

  • Primary or desctuctive ActionStyle is not supported in Microsoft Teams.

Adaptive Cards with messageBack action

To include a messageBack action with an Adaptive Card include the following details in the msteams object:

Note

You can include additional hidden properties in the data object, if required.

Property Description
type Set to messageBack.
displayText Optional. Used by the user in the chat stream when the action is performed. This text isn't sent to your bot.
value Sent to your bot when the action is performed. You can encode context for the action, such as unique identifiers or a JSON object.
text Sent to your bot when the action is performed. Use this property to simplify bot development. Your code can check a single top-level property to dispatch bot logic.

The following code shows an example of Adaptive Cards with messageBack action:

{
  "type": "Action.Submit",
  "title": "Click me for messageBack",
  "data": {
    "msteams": {
        "type": "messageBack",
        "displayText": "I clicked this button",
        "text": "text to bots",
        "value": "{\"bfKey\": \"bfVal\", \"conflictKey\": \"from value\"}"
    }
  }
}

Adaptive Cards with imBack action

To include an imBack action with an Adaptive Card include the following details in the msteams object:

Note

You can include additional hidden properties in the data object, if required.

Property Description
type Set to imBack.
value String that needs to be echoed back in the chat.

The following code shows an example of Adaptive Cards with imBack action:

{
  "type": "Action.Submit",
  "title": "Click me for imBack",
  "data": {
    "msteams": {
        "type": "imBack",
        "value": "Text to reply in chat"
    }
  }
}

Adaptive Cards with sign-in action

To include a signin action with an Adaptive Card include the following details in the msteams object:

Note

You can include additional hidden properties in the data object, if required.

Property Description
type Set to signin.
value Set to the URL where you want to redirect.

The following code shows an example of Adaptive Cards with signin action:

{
  "type": "Action.Submit",
  "title": "Click me for signin",
  "data": {
    "msteams": {
        "type": "signin",
        "value": "https://signin.com"
    }
  }
}

Adaptive Cards with invoke action

To include an invoke action with an Adaptive Card include the following details in the msteams object:

Note

You can include additional hidden properties in the data object, if required.

Property Description
type Set to task/fetch.
data Set the value.

The following code shows an example of Adaptive Cards with invoke action:

{
  "type": "Action.Submit",
  "title": "submit",
  "data": {
    "msteams": {
        "type": "task/fetch"
    }
  }
}

The following code shows an example of Adaptive Cards with invoke action with additional payload data:

{
  "type": "Action.Submit",
  "title": "submit"
  "data": {
    "msteams": {
        "type": "task/fetch"
    },
    "Value1": "some value"
  }
}

Code samples

S.No. Card Description .NET Node.js Python Java
1 Adaptive card actions This sample showscases different actions supported in adaptive cards. View View NA NA
2 Using cards Introduces all card types including thumbnail, audio, media etc. Builds on Welcoming user + multi-prompt bot by presenting a card with buttons in welcome message that route to appropriate dialog. View View View View
3 Adaptive cards Demonstrates how the multi-turn dialog can use a card to get user input for name and age. View View View View

Note

Media elements are not supported for adaptive card in Teams
