Tutorial: Configure replication between two managed instances

Applies to: Azure SQL Managed Instance

Transactional replication allows you to replicate data from one database to another hosted on either SQL Server or Azure SQL Managed Instance. SQL Managed Instance can be a publisher, distributor or subscriber in the replication topology. See transactional replication configurations for available configurations.

In this tutorial, you learn how to:

  • Configure a managed instance as a replication publisher and distributor.
  • Configure a managed instance as a replication subscriber.

Replicate between two managed instances

This tutorial is intended for an experienced audience and assumes that the user is familiar with deploying and connecting to both managed instances and SQL Server VMs within Azure.

Note

Requirements

Configuring SQL Managed Instance to function as a publisher and/or a distributor requires:

  • That the publisher managed instance is on the same virtual network as the distributor and the subscriber, or VNet peering or VPN gateways have been configured between the virtual networks of all three entities.
  • Connectivity uses SQL Authentication between replication participants.
  • An Azure storage account share for the replication working directory.
  • Port 445 (TCP outbound) is open in the security rules of NSG for the managed instances to access the Azure file share. If you encounter the error failed to connect to azure storage <storage account name> with os error 53, you will need to add an outbound rule to the NSG of the appropriate SQL Managed Instance subnet.

1 - Create a resource group

Use the Azure portal to create a resource group with the name SQLMI-Repl.

2 - Create managed instances

Use the Azure portal to create two SQL Managed Instances on the same virtual network and subnet. For example, name the two managed instances:

  • sql-mi-pub (along with some characters for randomization)
  • sql-mi-sub (along with some characters for randomization)

You will also need to configure an Azure VM to connect to your managed instances.

3 - Create an Azure storage account

Create an Azure storage account for the working directory, and then create a file share within the storage account.

Copy the file share path in the format of: \\storage-account-name.file.core.windows.net\file-share-name

Example: \\replstorage.file.core.windows.net\replshare

Copy the storage access keys in the format of: DefaultEndpointsProtocol=https;AccountName=<Storage-Account-Name>;AccountKey=****;EndpointSuffix=core.windows.net

Example: DefaultEndpointsProtocol=https;AccountName=replstorage;AccountKey=dYT5hHZVu9aTgIteGfpYE64cfis0mpKTmmc8+EP53GxuRg6TCwe5eTYWrQM4AmQSG5lb3OBskhg==;EndpointSuffix=core.windows.net

For more information, see Manage storage account access keys.

4 - Create a publisher database

Connect to your sql-mi-pub managed instance using SQL Server Management Studio and run the following Transact-SQL (T-SQL) code to create your publisher database:

USE [master]
GO

CREATE DATABASE [ReplTran_PUB]
GO

USE [ReplTran_PUB]
GO
CREATE TABLE ReplTest (
  ID INT NOT NULL PRIMARY KEY,
  c1 VARCHAR(100) NOT NULL,
  dt1 DATETIME NOT NULL DEFAULT getdate()
)
GO


USE [ReplTran_PUB]
GO

INSERT INTO ReplTest (ID, c1) VALUES (6, 'pub')
INSERT INTO ReplTest (ID, c1) VALUES (2, 'pub')
INSERT INTO ReplTest (ID, c1) VALUES (3, 'pub')
INSERT INTO ReplTest (ID, c1) VALUES (4, 'pub')
INSERT INTO ReplTest (ID, c1) VALUES (5, 'pub')
GO
SELECT * FROM ReplTest
GO

5 - Create a subscriber database

Connect to your sql-mi-sub managed instance using SQL Server Management Studio and run the following T-SQL code to create your empty subscriber database:

USE [master]
GO

CREATE DATABASE [ReplTran_SUB]
GO

USE [ReplTran_SUB]
GO
CREATE TABLE ReplTest (
  ID INT NOT NULL PRIMARY KEY,
  c1 VARCHAR(100) NOT NULL,
  dt1 DATETIME NOT NULL DEFAULT getdate()
)
GO

6 - Configure distribution

Connect to your sql-mi-pub managed instance using SQL Server Management Studio and run the following T-SQL code to configure your distribution database.

USE [master]
GO

EXEC sp_adddistributor @distributor = @@ServerName;
EXEC sp_adddistributiondb @database = N'distribution';
GO

7 - Configure publisher to use distributor

On your publisher SQL Managed Instance sql-mi-pub, change the query execution to SQLCMD mode and run the following code to register the new distributor with your publisher.

:setvar username loginUsedToAccessSourceManagedInstance
:setvar password passwordUsedToAccessSourceManagedInstance
:setvar file_storage "\\storage-account-name.file.core.windows.net\file-share-name"
-- example: file_storage "\\replstorage.file.core.windows.net\replshare"
:setvar file_storage_key "DefaultEndpointsProtocol=https;AccountName=<Storage-Account-Name>;AccountKey=****;EndpointSuffix=core.windows.net"
-- example: file_storage_key "DefaultEndpointsProtocol=https;AccountName=replstorage;AccountKey=dYT5hHZVu9aTgIteGfpYE64cfis0mpKTmmc8+EP53GxuRg6TCwe5eTYWrQM4AmQSG5lb3OBskhg==;EndpointSuffix=core.windows.net"

USE [master]
EXEC sp_adddistpublisher
  @publisher = @@ServerName,
  @distribution_db = N'distribution',
  @security_mode = 0,
  @login = N'$(username)',
  @password = N'$(password)',
  @working_directory = N'$(file_storage)',
  @storage_connection_string = N'$(file_storage_key)'; -- Remove this parameter for on-premises publishers

Note

Be sure to use only backslashes (\) for the file_storage parameter. Using a forward slash (/) can cause an error when connecting to the file share.

This script configures a local publisher on the managed instance, adds a linked server, and creates a set of jobs for the SQL Server agent.

8 - Create publication and subscriber

Using SQLCMD mode, run the following T-SQL script to enable replication for your database, and configure replication between your publisher, distributor, and subscriber.

-- Set variables
:setvar username sourceLogin
:setvar password sourcePassword
:setvar source_db ReplTran_PUB
:setvar publication_name PublishData
:setvar object ReplTest
:setvar schema dbo
:setvar target_server "sql-mi-sub.wdec33262scj9dr27.database.windows.net"
:setvar target_username targetLogin
:setvar target_password targetPassword
:setvar target_db ReplTran_SUB

-- Enable replication for your source database
USE [$(source_db)]
EXEC sp_replicationdboption
  @dbname = N'$(source_db)',
  @optname = N'publish',
  @value = N'true';

-- Create your publication
EXEC sp_addpublication
  @publication = N'$(publication_name)',
  @status = N'active';


-- Configure your log reader agent
EXEC sp_changelogreader_agent
  @publisher_security_mode = 0,
  @publisher_login = N'$(username)',
  @publisher_password = N'$(password)',
  @job_login = N'$(username)',
  @job_password = N'$(password)';

-- Add the publication snapshot
EXEC sp_addpublication_snapshot
  @publication = N'$(publication_name)',
  @frequency_type = 1,
  @publisher_security_mode = 0,
  @publisher_login = N'$(username)',
  @publisher_password = N'$(password)',
  @job_login = N'$(username)',
  @job_password = N'$(password)';

-- Add the ReplTest table to the publication
EXEC sp_addarticle
  @publication = N'$(publication_name)',
  @type = N'logbased',
  @article = N'$(object)',
  @source_object = N'$(object)',
  @source_owner = N'$(schema)';

-- Add the subscriber
EXEC sp_addsubscription
  @publication = N'$(publication_name)',
  @subscriber = N'$(target_server)',
  @destination_db = N'$(target_db)',
  @subscription_type = N'Push';

-- Create the push subscription agent
EXEC sp_addpushsubscription_agent
  @publication = N'$(publication_name)',
  @subscriber = N'$(target_server)',
  @subscriber_db = N'$(target_db)',
  @subscriber_security_mode = 0,
  @subscriber_login = N'$(target_username)',
  @subscriber_password = N'$(target_password)',
  @job_login = N'$(username)',
  @job_password = N'$(password)';

-- Initialize the snapshot
EXEC sp_startpublication_snapshot
  @publication = N'$(publication_name)';

9 - Modify agent parameters

Azure SQL Managed Instance is currently experiencing some backend issues with connectivity with the replication agents. While this issue is being addressed, the workaround is to increase the login timeout value for the replication agents.

Run the following T-SQL command on the publisher to increase the login timeout:

-- Increase login timeout to 150s
update msdb..sysjobsteps set command = command + N' -LoginTimeout 150'
where subsystem in ('Distribution','LogReader','Snapshot') and command not like '%-LoginTimeout %'

Run the following T-SQL command again to set the login timeout back to the default value, should you need to do so:

-- Increase login timeout to 30
update msdb..sysjobsteps set command = command + N' -LoginTimeout 30'
where subsystem in ('Distribution','LogReader','Snapshot') and command not like '%-LoginTimeout %'

Restart all three agents to apply these changes.

10 - Test replication

Once replication has been configured, you can test it by inserting new items on the publisher and watching the changes propagate to the subscriber.

Run the following T-SQL snippet to view the rows on the subscriber:

select * from dbo.ReplTest

Run the following T-SQL snippet to insert additional rows on the publisher, and then check the rows again on the subscriber.

INSERT INTO ReplTest (ID, c1) VALUES (15, 'pub')

Clean up resources

To drop the publication, run the following T-SQL command:

-- Drops the publication
USE [ReplTran_PUB]
EXEC sp_droppublication @publication = N'PublishData'
GO

To remove the replication option from the database, run the following T-SQL command:

-- Disables publishing of the database
USE [ReplTran_PUB]
EXEC sp_removedbreplication
GO

To disable publishing and distribution, run the following T-SQL command:

-- Drops the distributor
USE [master]
EXEC sp_dropdistributor @no_checks = 1
GO

You can clean up your Azure resources by deleting the SQL Managed Instance resources from the resource group and then deleting the resource group SQLMI-Repl.

Next steps

You can also learn more information about transactional replication with Azure SQL Managed Instance or learn to configure replication between a SQL Managed Instance publisher/distributor and a SQL on Azure VM subscriber.
