HTTP with Microsoft Entra ID (preauthorized)
Use the HTTP connector to fetch resources from various Web services, authenticated by Microsoft Entra ID, or from an on-premise web service.
This connector is available in the following products and regions:
Service | Class | Regions |
---|---|---|
Logic Apps | Standard | All Logic Apps regions except the following: - US Department of Defense (DoD) |
Power Automate | Premium | All Power Automate regions |
Power Apps | Premium | All Power Apps regions |
Contact | |
---|---|
Name | Microsoft |
URL | Microsoft LogicApps Support Microsoft Power Automate Support Microsoft Power Apps Support |
Connector Metadata | |
---|---|
Publisher | Microsoft |
Note
The HTTP with Microsoft Entra ID (preauthorized) connector enables users to submit requests to any HTTP endpoint that supports Entra ID authentication. As part of our ongoing efforts to enhance security and data privacy, we have reviewed the permissions associated with this connector and are planning to provide improved identity isolation controls.
Currently, the HTTP with Microsoft Entra ID (preauthorized) connector operates through a Microsoft 1st party trusted application. This application includes preauthorization for various Microsoft services, including but not limited to Microsoft Graph, SharePoint, and other Microsoft offerings. This preauthorization empowers the connector to interact with these services using delegated access on behalf of the user. Rest assured that this approach fully respects the user's privileges and does not permit access to data or actions beyond their authorized scope.
With the existing connector, there is no need for administrators to explicitly grant consent for actions to be executed by the application on behalf of the user. However, we released a new version of this connector. The new version of the connector uses a new application without any preauthorization. This allows an administrator to grant discrete consent.
If you wish to restrict the use of this connector, you can leverage the existing Data Loss Prevention (DLP) capabilities. You have the option to create a new policy or update an existing one to block the utilization of this connector. It is important to note that some other connectors and features depend on the HTTP with Microsoft Entra ID (preauthorized) connector. For additional information, click here.
Known Issues and Limitations
The connector encodes the request body into base64 encoding, hence it should be used to call backend services which expect the request body in this format. You cannot use this connector to call a backend service that expects the request body in raw binary format.
If you get an error similar to:
{ "error": { "code": "Forbidden", "message": "" } }
{ "error": { "code": "Authorization_RequestDenied", "message": "Insufficient privileges to complete the operation." } }
then it could be because this connector has a limited set of scopes.- Users may also face pre-authorization errors when connecting to some resources that are not supported.
- If your scenario requires something more advanced, please use the "HTTP" connector or create a custom connector.
The connector is based on multi-tenant application registration. The application cannot tell what tenant the user is from until the user signs into it. Therefore, we only support specifying resources under users' default tenant ('common').
Resources based on ADFS SSO (Microsoft Entra ID Federation Services for Single Sign-On) are not supported. As a workaround, please use the "HTTP" connector.
When using this connector in a national cloud environment the resource must be their national cloud endpoint equivalent. Attempts to try to connect to public cloud (https://graph.microsoft.com, https://bing.com for example) from most national cloud environments will fail with a pre-authorization error.
- GCC and Fairfax environments can continue to use public cloud endpoints (https://graph.microsoft.com, for example).
- GCC-High resource example: https://graph.microsoft.us.
- China resource example: https://microsoftgraph.chinacloudapi.cn.
The use of cookie authorization request header is not supported in case of on-premises data gateway enabled connection.
The asynchronous pattern based on the response Location header is not supported. Please use Azure Resource Manager connector instead if applicable.
Creating a connection
The connector supports the following authentication types:
Default | Parameters for creating connection. | All regions | Not shareable |
Default
Applicable: All regions
Parameters for creating connection.
This is not shareable connection. If the power app is shared with another user, another user will be prompted to create new connection explicitly.
Name | Type | Description | Required |
---|---|---|---|
Microsoft Entra ID Resource URI (Application ID URI) | string | The identifier used in Microsoft Entra ID to identify the target resource. For SharePoint Online and OneDrive for Business, use https://{contoso}.sharepoint.com. Usually, it is the base URL of your resource. | True |
Base Resource URL | string | Specify the base URL of the HTTP resources or Application (client) ID in the form of the GUID you want to connect to. | True |
Username | securestring | Username credential | |
Password | securestring | Password credential | |
Authentication Type | string | Authentication type to connect to your on-premise HTTP resource | |
Gateway | gatewaySetting | On-prem gateway (see https://docs.microsoft.com/data-integration/gateway for more details |
Throttling Limits
Name | Calls | Renewal Period |
---|---|---|
API calls per connection | 100 | 60 seconds |
Actions
Get web resource |
Retrieves a web resource by issuing an HTTP GET request. |
Invoke an HTTP request |
Invokes an HTTP endpoint. |
Get web resource
Retrieves a web resource by issuing an HTTP GET request.
Parameters
Name | Key | Required | Type | Description |
---|---|---|---|---|
Resource path
|
path | True | string |
File identifier |
Returns
The content of the file.
- File Content
- binary
Invoke an HTTP request
Invokes an HTTP endpoint.
Parameters
Name | Key | Required | Type | Description |
---|---|---|---|---|
Method
|
method | True | string |
One of the known HTTP verbs: GET, DELETE, PATCH, POST, PUT. |
Url of the request
|
url | True | string |
A full or relative URL to the resource. If it is a full URL , it must match the base resource URL set in the connection. |
Headers
|
headers | object |
The request headers. |
|
Body of the request
|
body | byte |
Body of the request when the method requires it. |
Returns
The content of the response.
- Body
- string
Definitions
binary
This is the basic data type 'binary'.
