Quickstart: Create SQL Server on a Windows virtual machine in the Azure portal

Applies to: SQL Server on Azure VM

This quickstart steps through creating a SQL Server virtual machine (VM) in the Azure portal. Follow the article to deploy either a conventional SQL Server on Azure VM, or SQL Server deployed to an Azure confidential VM.

Tip

Get an Azure subscription

If you don't have an Azure subscription, create a free account before you begin.

Select a SQL Server VM image

  1. Sign in to the Azure portal using your account.

  2. Select Azure SQL in the left-hand menu of the Azure portal. If Azure SQL is not in the list, select All services, then type Azure SQL in the search box.

  3. Select +Add to open the Select SQL deployment option page. You can view additional information by selecting Show details on the SQL virtual machines tile.

  4. For conventional SQL Server VMs, select one of the versions labeled Free SQL Server License... from the drop-down. For confidential VMs, choose the SQL Server 2019 Enterprise on Windows Server 2022 Database Engine Only image from the drop-down.

    Screenshot that shows where you select the Free SQL Server License: SQL Server 2017 Developer on Windows Server 2016 image.

  5. Select Create.

    New search window

Note

SQL Server 2008 and SQL Server 2008 R2 are out of extended support and no longer available from the Azure Marketplace.

Provide basic details

The instructions for basic details vary between deploying a conventional SQL Server on Azure VM, and SQL Server on an Azure confidential VM.

To deploy a conventional SQL Server on Azure VM, on the Basics tab, provide the following information:

  1. In the Project Details section, select your Azure subscription and then select Create new to create a new resource group. Type SQLVM-RG for the name.

    Subscription

  2. Under Instance details:

    1. Type SQLVM for the Virtual machine name.
    2. Choose a location for your Region.
    3. For the purpose of this quickstart, leave Availability options set to No infrastructure redundancy required. To find out more information about availability options, see Availability.
    4. In the Image list, select the image with the version of SQL Server and operating system you want. For example, you can use an image with a label that begins with Free SQL Server License:.
    5. Choose to Change size for the Size of the virtual machine and select the A2 Basic offering. Be sure to clean up your resources once you're done with them to prevent any unexpected charges.

    Instance details

  3. Under Administrator account, provide a username, such as azureuser and a password. The password must be at least 12 characters long and meet the defined complexity requirements.

    Administrator account

  4. Under Inbound port rules, choose Allow selected ports and then select RDP (3389) from the drop-down.

    Inbound port rules

SQL Server settings

On the SQL Server settings tab, configure the following options:

  1. Under Security & Networking, select Public (Internet) for SQL Connectivity and change the port to 1401 to avoid using a well-known port number in the public scenario.

  2. Under SQL Authentication, select Enable. The SQL login credentials are set to the same user name and password that you configured for the VM. Use the default setting for Azure Key Vault integration. Storage configuration is not available for the basic SQL Server VM image, but you can find more information about available options for other images at storage configuration.

    SQL Server security settings

  3. Change any other settings if needed, and then select Review + create.

    Review + create

Create the SQL Server VM

On the Review + create tab, review the summary, and select Create to create SQL Server, resource group, and resources specified for this VM.

You can monitor the deployment from the Azure portal. The Notifications button at the top of the screen shows basic status of the deployment. Deployment can take several minutes.

Connect to SQL Server

  1. In the portal, find the Public IP address of your SQL Server VM in the Overview section of your virtual machine's properties.

  2. On a different computer connected to the Internet, open SQL Server Management Studio (SSMS).

  3. In the Connect to Server or Connect to Database Engine dialog box, edit the Server name value. Enter your VM's public IP address. Then add a comma and add the custom port (1401) that you specified when you configured the new VM. For example, 11.22.33.444,1401.

  4. In the Authentication box, select SQL Server Authentication.

  5. In the Login box, type the name of a valid SQL login.

  6. In the Password box, type the password of the login.

  7. Select Connect.

    ssms connect

Log in to the VM remotely

Use the following steps to connect to the SQL Server virtual machine with Remote Desktop:

  1. After the Azure virtual machine is created and running, select Virtual machine, and then choose your new VM.

  2. Select Connect and then choose RDP from the drop-down to download your RDP file.

    Connect to VM in portal

  3. Open the RDP file that your browser downloads for the VM.

  4. The Remote Desktop Connection notifies you that the publisher of this remote connection cannot be identified. Click Connect to continue.

  5. In the Windows Security dialog, click Use a different account. You might have to click More choices to see this. Specify the user name and password that you configured when you created the VM. You must add a backslash before the user name.

    Remote desktop authentication

  6. Click OK to connect.

After you connect to the SQL Server virtual machine, you can launch SQL Server Management Studio and connect with Windows Authentication using your local administrator credentials. If you enabled SQL Server Authentication, you can also connect with SQL Authentication using the SQL login and password you configured during provisioning.

Access to the machine enables you to directly change machine and SQL Server settings based on your requirements. For example, you could configure the firewall settings or change SQL Server configuration settings.

Clean up resources

If you do not need your SQL VM to run continually, you can avoid unnecessary charges by stopping it when not in use. You can also permanently delete all resources associated with the virtual machine by deleting its associated resource group in the portal. This permanently deletes the virtual machine as well, so use this command with care. For more information, see Manage Azure resources through portal.

Next steps

In this quickstart, you created a SQL Server virtual machine in the Azure portal. To learn more about how to migrate your data to the new SQL Server, see the following article.
