这是一个DPC或者ISR执行时间过长导致超时的错误,多半是硬件驱动问题、硬件故障或者是CPU/内存极高负载导致的,可以通过更新或者回滚驱动(解决第一个问题)、观察平时有没有此情况(排查第二个问题)和关注使用率(排查第三个问题)解决
*******************************************************************************
* *
* Bugcheck Analysis *
* *
*******************************************************************************
DPC_WATCHDOG_VIOLATION (133)
The DPC watchdog detected a prolonged run time at an IRQL of DISPATCH_LEVEL
or above.
Arguments:
Arg1: 0000000000000000, A single DPC or ISR exceeded its time allotment. The offending
component can usually be identified with a stack trace.
Arg2: 0000000000000501, The DPC time count (in ticks).
Arg3: 0000000000000500, The DPC time allotment (in ticks).
Arg4: fffff80276905330, cast to nt!DPC_WATCHDOG_GLOBAL_TRIAGE_BLOCK, which contains
additional information regarding this single DPC timeout
Debugging Details:
------------------
*************************************************************************
*** ***
*** ***
*** Either you specified an unqualified symbol, or your debugger ***
*** doesn't have full symbol information. Unqualified symbol ***
*** resolution is turned off by default. Please either specify a ***
*** fully qualified symbol module!symbolname, or enable resolution ***
*** of unqualified symbols by typing ".symopt- 100". Note that ***
*** enabling unqualified symbol resolution with network symbol ***
*** server shares in the symbol path may cause the debugger to ***
*** appear to hang for long periods of time when an incorrect ***
*** symbol name is typed or the network symbol server is down. ***
*** ***
*** For some commands to work properly, your symbol path ***
*** must point to .pdb files that have full type information. ***
*** ***
*** Certain .pdb files (such as the public OS symbols) do not ***
*** contain the required information. Contact the group that ***
*** provided you with these symbols if you need this command to ***
*** work. ***
*** ***
*** Type referenced: TickPeriods ***
*** ***
*************************************************************************
KEY_VALUES_STRING: 1
Key : Analysis.CPU.mSec
Value: 3218
Key : Analysis.Elapsed.mSec
Value: 20474
Key : Analysis.IO.Other.Mb
Value: 6
Key : Analysis.IO.Read.Mb
Value: 1
Key : Analysis.IO.Write.Mb
Value: 13
Key : Analysis.Init.CPU.mSec
Value: 562
Key : Analysis.Init.Elapsed.mSec
Value: 34085
Key : Analysis.Memory.CommitPeak.Mb
Value: 102
Key : Analysis.Version.DbgEng
Value: 10.0.27829.1001
Key : Analysis.Version.Description
Value: 10.2503.24.01 amd64fre
Key : Analysis.Version.Ext
Value: 1.2503.24.1
Key : Bugcheck.Code.LegacyAPI
Value: 0x133
Key : Bugcheck.Code.TargetModel
Value: 0x133
Key : Dump.Attributes.AsUlong
Value: 0x1008
Key : Dump.Attributes.DiagDataWrittenToHeader
Value: 1
Key : Dump.Attributes.ErrorCode
Value: 0x0
Key : Dump.Attributes.KernelGeneratedTriageDump
Value: 1
Key : Dump.Attributes.LastLine
Value: Dump completed successfully.
Key : Dump.Attributes.ProgressPercentage
Value: 0
Key : Failure.Bucket
Value: 0x133_DPC_nt!KeAccumulateTicks
Key : Failure.Hash
Value: {88dc98ce-f842-4daa-98d0-858621db6b0f}
Key : Stack.Pointer
Value: ISR
BUGCHECK_CODE: 133
BUGCHECK_P1: 0
BUGCHECK_P2: 501
BUGCHECK_P3: 500
BUGCHECK_P4: fffff80276905330
FILE_IN_CAB: 051925-8406-01.dmp
DUMP_FILE_ATTRIBUTES: 0x1008
Kernel Generated Triage Dump
FAULTING_THREAD: b
DPC_TIMEOUT_TYPE: SINGLE_DPC_TIMEOUT_EXCEEDED
BLACKBOXBSD: 1 (!blackboxbsd)
BLACKBOXNTFS: 1 (!blackboxntfs)
BLACKBOXPNP: 1 (!blackboxpnp)
BLACKBOXWINLOGON: 1
CUSTOMER_CRASH_COUNT: 1
PROCESS_NAME: System
STACK_TEXT:
ffffb901`75ab49e8 fffff802`75f2d6be : 00000000`00000133 00000000`00000000 00000000`00000501 00000000`00000500 : nt!KeBugCheckEx
ffffb901`75ab49f0 fffff802`75f2d141 : 00000170`811e4698 ffffb901`00000500 00000000`00000297 fffff802`75f9c945 : nt!KeAccumulateTicks+0x39e
ffffb901`75ab4a60 fffff802`75f2a176 : 00000000`00009229 00000000`0000571e 00000001`5c791509 00000000`00000000 : nt!KiUpdateRunTime+0x61
ffffb901`75ab4ac0 fffff802`75f2b482 : fffff105`542cee80 00000000`00000000 fffff802`7682b3a0 00000000`00000000 : nt!KiUpdateTime+0x686
ffffb901`75ab4eb0 fffff802`75f28db2 : fffff105`542cee80 ffff8008`5114c210 ffff8008`00000000 00000000`00000002 : nt!KeClockInterruptNotify+0x272
ffffb901`75ab4f40 fffff802`75f15e40 : 00000001`5c90774f ffff8008`5114c160 00000000`00000001 ffff8008`51143040 : nt!HalpTimerClockInterrupt+0xe2
ffffb901`75ab4f70 fffff802`7601f8ca : fffff105`542cef00 ffff8008`5114c160 00000000`00000000 ffffb901`75a50fe0 : nt!KiCallInterruptServiceRoutine+0xa0
ffffb901`75ab4fb0 fffff802`76020137 : 00000000`00000000 00000000`00000000 fffff105`542cf098 fffff802`76020144 : nt!KiInterruptSubDispatchNoLockNoEtw+0xfa
fffff105`542cee80 fffff802`75e5c58c : ffffffff`ffffffd1 fffff802`75e5c872 00000000`00000010 00000000`00000286 : nt!KiInterruptDispatchNoLockNoEtw+0x37
fffff105`542cf010 fffff802`75e5c883 : 00000000`00000000 00000000`00000000 00000000`00000000 00000000`00000000 : nt!KeYieldProcessorEx+0x1c
fffff105`542cf040 fffff802`75f1d391 : fffff105`542cf400 fffff105`1bf62129 ffffb901`75a4c4c0 00000000`00000000 : nt!KiSwapDirectoryTableBaseTarget+0x53
fffff105`542cf090 fffff802`75f1c392 : 00000000`00000000 00000000`00000000 00000000`00000000 00000000`00000000 : nt!KiExecuteAllDpcs+0x491
fffff105`542cf290 fffff802`7602253e : 00000000`00000000 ffffb901`75a49180 ffffb901`75a55340 ffff8008`819a5080 : nt!KiRetireDpcList+0x2a2
fffff105`542cf540 00000000`00000000 : fffff105`542d0000 fffff105`542c9000 00000000`00000000 00000000`00000000 : nt!KiIdleLoop+0x9e
STACK_COMMAND: ~11 ; .cxr ; kb
SYMBOL_NAME: nt!KeAccumulateTicks+39e
MODULE_NAME: nt
IMAGE_NAME: ntkrnlmp.exe
IMAGE_VERSION: 10.0.22000.2538
BUCKET_ID_FUNC_OFFSET: 39e
FAILURE_BUCKET_ID: 0x133_DPC_nt!KeAccumulateTicks
OSPLATFORM_TYPE: x64
OSNAME: Windows 10
FAILURE_ID_HASH: {88dc98ce-f842-4daa-98d0-858621db6b0f}
Followup: MachineOwner
---------
