向 Azure 服务总线队列发送消息并从中接收消息 (Python)

本文介绍如何使用 Python 向 Azure 服务总线队列发送消息,并从中接收消息。

注意

本快速入门分步介绍了一个简单方案,也就是将消息发送到服务总线队列并接收这些消息。 可在 GitHub 上的 Azure SDK for Python 存储库中找到 Azure 服务总线的预生成 JavaScript 和 TypeScript 示例。

先决条件

向队列发送消息

  1. 添加以下 import 语句。

    from azure.servicebus import ServiceBusClient, ServiceBusMessage

  2. 添加以下常量。

    CONNECTION_STR = "<NAMESPACE CONNECTION STRING>"
    QUEUE_NAME = "<QUEUE NAME>"


    重要

    • <NAMESPACE CONNECTION STRING> 替换为服务总线命名空间的连接字符串。
    • <QUEUE NAME> 替换为该队列的名称。
  3. 添加一个方法以发送一条消息。

    def send_single_message(sender):
        # create a Service Bus message
        message = ServiceBusMessage("Single Message")
        # send the message to the queue
        sender.send_messages(message)
        print("Sent a single message")


    发送方是一个对象,充当你创建的队列的客户端。 稍后将创建它,并将其作为参数发送到此函数。

  4. 添加一个方法以发送一列消息。

    def send_a_list_of_messages(sender):
        # create a list of messages
        messages = [ServiceBusMessage("Message in list") for _ in range(5)]
        # send the list of messages to the queue
        sender.send_messages(messages)
        print("Sent a list of 5 messages")

  5. 添加一个方法以发送一批消息。

    def send_batch_message(sender):
        # create a batch of messages
        batch_message = sender.create_message_batch()
        for _ in range(10):
            try:
                # add a message to the batch
                batch_message.add_message(ServiceBusMessage("Message inside a ServiceBusMessageBatch"))
            except ValueError:
                # ServiceBusMessageBatch object reaches max_size.
                # New ServiceBusMessageBatch object can be created here to send more data.
                break
        # send the batch of messages to the queue
        sender.send_messages(batch_message)
        print("Sent a batch of 10 messages")

  6. 创建一个服务总线客户端,然后创建一个队列发送方对象来发送消息。

    # create a Service Bus client using the connection string
    servicebus_client = ServiceBusClient.from_connection_string(conn_str=CONNECTION_STR, logging_enable=True)
    with servicebus_client:
        # get a Queue Sender object to send messages to the queue
        sender = servicebus_client.get_queue_sender(queue_name=QUEUE_NAME)
        with sender:
            # send one message
            send_single_message(sender)
            # send a list of messages
            send_a_list_of_messages(sender)
            # send a batch of messages
            send_batch_message(sender)

    print("Done sending messages")
    print("-----------------------")


从队列接收消息

在 print 语句的后面添加以下代码。 此代码将持续接收新消息,直到在 5 (max_wait_time) 秒内未收到任何新消息。

with servicebus_client:
    # get the Queue Receiver object for the queue
    receiver = servicebus_client.get_queue_receiver(queue_name=QUEUE_NAME, max_wait_time=5)
    with receiver:
        for msg in receiver:
            print("Received: " + str(msg))
            # complete the message so that the message is removed from the queue
            receiver.complete_message(msg)

完整代码

# import os
from azure.servicebus import ServiceBusClient, ServiceBusMessage

CONNECTION_STR = "<NAMESPACE CONNECTION STRING>"
QUEUE_NAME = "<QUEUE NAME>"

def send_single_message(sender):
    message = ServiceBusMessage("Single Message")
    sender.send_messages(message)
    print("Sent a single message")

def send_a_list_of_messages(sender):
    messages = [ServiceBusMessage("Message in list") for _ in range(5)]
    sender.send_messages(messages)
    print("Sent a list of 5 messages")

def send_batch_message(sender):
    batch_message = sender.create_message_batch()
    for _ in range(10):
        try:
            batch_message.add_message(ServiceBusMessage("Message inside a ServiceBusMessageBatch"))
        except ValueError:
            # ServiceBusMessageBatch object reaches max_size.
            # New ServiceBusMessageBatch object can be created here to send more data.
            break
    sender.send_messages(batch_message)
    print("Sent a batch of 10 messages")

servicebus_client = ServiceBusClient.from_connection_string(conn_str=CONNECTION_STR, logging_enable=True)

with servicebus_client:
    sender = servicebus_client.get_queue_sender(queue_name=QUEUE_NAME)
    with sender:
        send_single_message(sender)
        send_a_list_of_messages(sender)
        send_batch_message(sender)

print("Done sending messages")
print("-----------------------")

with servicebus_client:
    receiver = servicebus_client.get_queue_receiver(queue_name=QUEUE_NAME, max_wait_time=5)
    with receiver:
        for msg in receiver:
            print("Received: " + str(msg))
            receiver.complete_message(msg)

运行应用

运行应用程序时,应显示以下输出:

Sent a single message
Sent a list of 5 messages
Sent a batch of 10 messages
Done sending messages
-----------------------
Received: Single Message
Received: Message in list
Received: Message in list
Received: Message in list
Received: Message in list
Received: Message in list
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch
Received: Message inside a ServiceBusMessageBatch

在 Azure 门户中,导航到你的服务总线命名空间。 在“概述”页上,验证传入和传出消息计数是否为 16 。 如果没有看到这些消息,请等待几分钟后再刷新页面。

传入和传出消息计数

在此“概述”页上选择队列,导航到“服务总线队列”页面 。 还可在此页上看到传入和传出消息计数 。 还可看到其他信息,如队列的当前大小和活动消息计数 。

队列详细信息

后续步骤

请参阅以下文档和示例:
