Get started with Azure Maps Power BI visual (Preview)
APPLIES TO: Power BI service for consumers Power BI service for designers & developers Power BI Desktop Requires Pro or Premium license
This article shows how to use the Microsoft Azure Maps Power BI visual.
This visual can be created and viewed in both Power BI Desktop and the Power BI service. The steps and illustrations in this article are from Power BI Desktop.
The Azure Maps Power BI visual provides a rich set of data visualizations for spatial data on top of a map. It's estimated that over 80% of business data has a location context. The Azure Maps Power BI visual can be used to gain insights into how this location context relates to and influences your business data.
What is sent to Azure?
The Azure Maps Power BI visual connects to cloud service hosted in Azure to retrieve location data such as map images and coordinates that are used to create the map visualization.
- Details about the area the map is focused on are sent to Azure to retrieve images needed to render the map canvas (also known as map tiles).
- Data in the Location, Latitude, and Longitude buckets may be sent to Azure to retrieve map coordinates (a process called geocoding).
- Telemetry data may be collected on the health of the visual (for example, crash reports), if the telemetry option in Power BI is enabled.
Other than the scenarios described above, no other data overlaid on the map is sent to the Azure Maps servers. All rendering of data happens locally within the client.
You, or your administrator, may need to update your firewall to allow access to the Azure Maps platform that uses the following URL.
Azure Maps Power BI visual behavior and requirements
There are a few considerations and requirements for the Azure Maps Power BI visual:
- The Azure Maps Power BI visual must be enabled in Power BI Desktop. To enable Azure Maps Power BI visual, select File > Options and Settings > Options > Preview features, then select the Azure Maps Visual checkbox. If the Azure Maps visual isn't available after enabling this setting, it's likely that a tenant admin switch in the Admin Portal needs to be enabled.
- The data set must have fields that contain latitude and longitude information.
Use the Azure Maps Power BI visual
Once the Azure Maps Power BI visual is enabled, select the Azure Maps icon from the Visualizations pane.
Power BI creates an empty Azure Maps visual design canvas. While in preview, another disclaimer is displayed.
Take the following steps to load the Azure Maps visual:
In the Fields pane, drag data fields that contain latitude and longitude coordinate information into the Latitude and/or Longitude buckets. This is the minimal data needed to load the Azure Maps visual.
To color the data based on categorization, drag a categorical field into the Legend bucket of the Fields pane. In this example, we're using the AdminDistrict column (also known as state or province).
The built-in legend control for Power BI does not currently appear in this preview.
To scale the data relatively, drag a measure into the Size bucket of the Fields pane. In this example, we're using Sales column.
Use the options in the Format pane to customize how data is rendered. The following image is the same map as above, but with the bubble layers fill transparency option set to 50% and the high-contrast outline option enabled.
You can also show or hide labels in the Format pane. The following two images show maps with the Show labels setting turned on and off:
Fields pane buckets
The following data buckets are available in the Fields pane of the Azure Maps visual.
|Latitude||The field used to specify the latitude value of the data points. Latitude values should be between -90 and 90 in decimal degrees format.|
|Longitude||The field used to specify the longitude value of the data points. Longitude values should be between -180 and 180 in decimal degrees format.|
|Legend||The field used to categorize the data and assign a unique color for data points in each category. When this bucket is filled, a Data colors section will appear in the Format pane that allows adjustments to the colors.|
|Size||The measure used for relative sizing of data points on the map.|
|Tooltips||Other data fields to display in tooltips when shapes are hovered.|
The Map settings section of the Format pane provide options for customizing how the map is displayed and reacts to updates.
The following settings are available in the Style section:
|Style||The style of the map. The dropdown list contains greyscale light, greyscale dark, night, road shaded relief, satellite and satellite road labels.|
|Show labels||A toggle switch that enables you to either show or hide map labels. For more information, see list item number five in the previous section.|
The following settings available in the View section enable the user to specify the default map view information when the Auto zoom setting is set to Off.
|Auto zoom||Automatically zooms the map into the data loaded through the Fields pane of the visual. As the data changes, the map will update its position accordingly. When Auto zoom is set to Off, the remaining settings in this section become active that enable to user to define the default map view.|
|Zoom||The default zoom level of the map. Can be a number between 0 and 22.|
|Center latitude||The default latitude of the center of the map.|
|Center longitude||The default longitude of the center of the map.|
|Heading||The default orientation of the map in degrees, where 0 is north, 90 is east, 180 is south, and 270 is west. Can be any number between 0 and 360.|
|Pitch||The default tilt of the map in degrees between 0 and 60, where 0 is looking straight down at the map.|
The following settings are available in the Controls section:
|World wrap||Allows the user to pan the map horizontally infinitely.|
|Style picker||Adds a button to the map that allows the report readers to change the style of the map.|
|Navigation||Adds buttons to the map as another method to allow the report readers to zoom, rotate, and change the pitch of the map. See this document on Navigating the map for details on all the different ways users can navigate the map.|
|Selection||Adds a button that allows the user to choose between different modes to select data on the map; circle, rectangle, polygon (lasso), or travel time or distance. To complete drawing a polygon; select the first point, or double-click on the last point on the map, or press the
|Geocoding culture||The default, Auto, refers to the Western Address System. The only other option, JA, refers to the Japanese address system. In the western address system, you begin with the address details and then proceed to the larger categories such as city, state and postal code. In the Japanese address system, the larger categories are listed first and finish with the address details.|
Considerations and Limitations
The Azure Maps Power BI visual is available in the following services and applications:
|Power BI Desktop||Yes|
|Power BI service (app.powerbi.com)||Yes|
|Power BI mobile applications||Yes|
|Power BI publish to web||No|
|Power BI Embedded||No|
|Power BI service embedding (PowerBI.com)||Yes|
Where is Azure Maps available?
At this time, Azure Maps is currently available in all countries and regions except:
- South Korea
- Azure Government (GCC + GCC High)
For coverage details for the different Azure Maps services that power this visual, see the Geographic coverage information document.
Which web browsers are supported by the Azure Maps Power BI visual?
See this documentation for information on Azure Maps Web SDK supported browsers.
How many data points can I visualize?
This visual supports up to 30,000 data points.
Can addresses or other location strings be used in this visual?
The initial preview of this visual only supports latitude and longitude values in decimal degrees. A future update will add support for addresses and other location strings.
