How to get Retention Labels using Graph Api - https://graph.microsoft.com/beta/security/labels/retentionLabels/12e43d75-6cbe-4330-8864-0baaf2614c25

Question

Tenant:

Graph beta version for Retention Label not working in oclabs tenant. Error is 401 Unauthorized

Tried in Graph Explorer and PowerShell script

1. https://graph.microsoft.com/beta/security/labels/retentionLabels/12e43d75-6cbe-4330-8864-0baaf2614c25
2. Import-Module Microsoft.Graph.Beta.Security

#List retentionLabels
Get-MgBetaSecurityLabelRetentionLabel

#Get retentionLabels
$retentionLabelId='12e43d75-6cbe-4330-8864-0baaf2614c25'
Get-MgBetaSecurityLabelRetentionLabel -RetentionLabelId $retentionLabelId

Answer 1

Hi @Ajay Kadavath

Error 401 occurs when you do not have permissions to the resource you are trying to access. To access the /beta/security/labels/retentionLabels/{id} you need the following permissions:

• RecordsManagement.Read.All

On graph explorer (https://developer.microsoft.com/en-us/graph/graph-explorer) before running the query, click on "Modify Permissions" and consent to that permission.

Here is the documentation for more details: https://learn.microsoft.com/en-us/graph/api/security-retentionlabel-get?view=graph-rest-beta&tabs=http

If the answer is helpful, please click "Accept Answer" and kindly upvote it. If you have extra questions about this answer, please click "Comment".

Answer 2

Tried using PnP PowerShell and Beta version of Graph Security approach

PnP PowerShell Approach

Import-Module PnP.PowerShell

Register-PnPAzureADApp -ApplicationName "RL Graph API" -Tenant "oclabs.onmicrosoft.com -Store CurrentUser -ValidYears 2 -CertificatePassword (ConvertTo-SecureString -String "password" -AsPlainText -Force) -Interactive

$connect = Connect-PnPOnline -ClientId $ClientId -Thumbprint $CertificateThumbprint -Tenant $Tenant -Url "https://oclabs.sharepoint.com -ReturnConnection

Get-PnPSite -Connection $connect

#working
$token = Get-PnPGraphAccessToken -Connection $connect

# Create header with the access token

$header = @{ Authorization = "Bearer $($token)" }

#v1.0/Beta

$uri = 'https://graph.microsoft.com/Beta/groups' + `

       '?$filter=resourceProvisioningOptions/Any(x:x eq ''Team'')' +

       '&select=id,displayName'

# Make a simple rest call

$response = Invoke-RestMethod -Uri $uri -Headers $header -Method Get -ContentType "application/json" -CertificateThumbprint $CertificateThumbprint

#$response = Invoke-PnPGraphMethod -Url $uri -Connection $connect -Method Get -ContentType "application/json" -All

# Lets see the result

$response.Value


#Not working#used delegated permission RecordsManagement.Read.All and RecordsManagement.ReadWrite.All #Security & Compliance PowerShell

$token = Get-PnPGraphAccessToken -Connection $connect #-Decoded

#$token = Get-PnPAppAuthAccessToken -Connection $connect

#GET https://graph.microsoft.com/v1.0/me/drive/root/search(q='retentionLabel:"12e43d75-6cbe-4330-8864-0baaf2614c25"')?$select=name,id,parentReference

$uri = 'https://graph.microsoft.com/beta/security/labels/retentionLabels'

$me = Invoke-RestMethod -Uri $uri -Headers @{"Authorization"="Bearer $($token)"} -Method Get -ContentType "application/json" -CertificateThumbprint $CertificateThumbprint$me.value

$me = Invoke-PnPGraphMethod -Url $uri -Connection $connect -Method Get -ContentType "application/json" -All #-Content @{"Authorization"="Bearer $($token)"} #-AdditionalHeaders @{"Authorization"="Bearer $($token)"}

$me.value

Graph PowerShell Approach

Get-Variable Max*Count
$MaximumFunctionCount = 8192
$MaximumVariableCount = 8192
#$MaximumAliasCount
#$MaximumErrorCount
#$MaximumHistoryCount
#$MaximumDriveCount

if ($PSVersionTable.PSEdition -eq 'Desktop') {
    $Script:MaximumFunctionCount = 18000
    $Script:MaximumVariableCount = 18000
}

#loading time max 5 min
Import-Module Microsoft.Graph
Import-Module Microsoft.Graph.Beta.Security

$RequiredScopes = ("Application.ReadWrite.All", "Organization.ReadWrite.All”, "Directory.Read.All", "User.Read.All", "Group.ReadWrite.All", "RecordsManagement.Read.All", "RecordsManagement.ReadWrite.All")

Connect-MgGraph -ClientId $ClientId -TenantId $TenantId -Scopes $RequiredScopes -NoWelcome

(Get-MgContext).Scopes

# Get context for access to tenant ID
$context = Get-MgContext

#List retentionLabels
Get-MgBetaSecurityLabelRetentionLabel

#Get retentionLabel
#Not working
$retentionLabelId='037098c7-57a3-4042-9287-67f84ab4e820'
Get-MgBetaSecurityLabelRetentionLabel -RetentionLabelId $retentionLabelId
