ServiceNow

ServiceNow improves service levels, energizes employees, and enables your enterprise to work at lightspeed. Create, read and update records stored within ServiceNow including Incidents, Questions, Users and more.

This connector is available in the following products and regions:

Service Class Regions
Logic Apps Standard All Logic Apps regions except the following:
     -   US Department of Defense (DoD)
Power Automate Premium All Power Automate regions except the following:
     -   China Cloud operated by 21Vianet
Power Apps Premium All Power Apps regions except the following:
     -   China Cloud operated by 21Vianet
Connector Metadata
Publisher Microsoft
Website https://www.servicenow.com/
Privacy policy https://www.servicenow.com/privacy-statement.html

Note

The Get Knowledge Articles operation can only be used when the Knowledge API (sn_km_api) plugin is activated.

Known Issues and Limitations

  1. When using the Create Record action, it's not possible to specify the full record description. The field value will be ignored due to Service-Now REST API limitations.

  2. The Get Records action may return an "Invalid Table" or other error in Power Apps. For Power Apps implementations the suggested work around is to utilize the Get Records action in Power Automate and pass the data back to Power Apps.

Creating a connection

The connector supports the following authentication types:

Use Oauth2 Sign in with Oauth2 All regions Not shareable
Basic Authentication Sign in using basic authentication All regions Not shareable
Microsoft Entra ID OAuth using Certificate OAuth with Microsoft Entra ID using PFX certificate. All regions Shareable
Default [DEPRECATED] This option is only for older connections without an explicit authentication type, and is only provided for backward compatibility. All regions Not shareable

Use Oauth2

Auth ID: oauth2ServiceNow

Applicable: All regions

Sign in with Oauth2

This is not shareable connection. If the power app is shared with another user, another user will be prompted to create new connection explicitly.

Name Type Description Required
Instance Name string The instance name used to identify the ServiceNow Site URl True
Client Id string The ID used to identify this application with the service provider True
Client secret securestring The shared secret used to authenticate this application with the service provider True

Basic Authentication

Auth ID: basicAuthentication

Applicable: All regions

Sign in using basic authentication

This is not shareable connection. If the power app is shared with another user, another user will be prompted to create new connection explicitly.

Name Type Description Required
Instance string Name of the instance for service-now.com or custom URL for migrated account True
Username string Username for this instance True
Password securestring The password for this account True

Microsoft Entra ID OAuth using Certificate

Auth ID: aadOAuthCert

Applicable: All regions

OAuth with Microsoft Entra ID using PFX certificate.

This is shareable connection. If the power app is shared with another user, connection is shared as well. For more information, please see the Connectors overview for canvas apps - Power Apps | Microsoft Docs

Name Type Description Required
Instance Name string The instance name used to identify the ServiceNow Site URl True
Tenant ID string True
Client ID string True
Resource URI string True
Client certificate secret clientCertificate The client certificate secret allowed by this application True

Default [DEPRECATED]

Applicable: All regions

This option is only for older connections without an explicit authentication type, and is only provided for backward compatibility.

This is not shareable connection. If the power app is shared with another user, another user will be prompted to create new connection explicitly.

Name Type Description Required
Instance string Name of the instance for service-now.com or custom URL for migrated account True
Username string Username for this instance True
Password securestring The password for this account True

Throttling Limits

Name Calls Renewal Period
API calls per connection 600 60 seconds

Actions

Create Record

Create a record in a ServiceNow table.

Delete an attachment (Preview)

Delete an attachment

Delete Record

Deletes a record for a ServiceNow object type like 'Incidents

Get Attachment Metadata (Preview)

Retrieve metadata for attachments

Get Knowledge Articles

Returns a list of knowledge base (KB) articles which can be searched and filtered

Get Record

Gets a record for a ServiceNow object type like 'Incidents'

Get Record Types

Lists the available record types

List Records

Gets records of a certain ServiceNow object type like 'Incidents'

Retrieve attachment content (Preview)

Retrieve attachment content

Retrieve attachment metadata (Preview)

Retrieve attachment metadata

Update Record

Updates a record for a ServiceNow object type like 'Incidents'

Upload an attachment (Preview)

Upload an attachment from a multipart form

Create Record

Create a record in a ServiceNow table.

Parameters

Name Key Required Type Description
Record Type
tableType True string

Type of record to list

body
body True dynamic
Display System References
sysparm_display_value boolean

Determines if system references should be included

Exclude Reference Links
sysparm_exclude_reference_link boolean

Determines if reference links should be excluded

Returns

The outputs of this operation are dynamic.

Delete an attachment (Preview)

Delete an attachment

Parameters

Name Key Required Type Description
sys_id
sys_id True string

Delete Record

Deletes a record for a ServiceNow object type like 'Incidents

Parameters

Name Key Required Type Description
Record Type
tableType True string

Type of record to list

System ID
sysid True string

System ID for the record.

Get Attachment Metadata (Preview)

Retrieve metadata for attachments

Parameters

Name Key Required Type Description
sysparm_limit
sysparm_limit string

Limit to be applied on pagination. Note: Unusually large sysparm_limit values can impact system performance. Default: 1000

sysparm_offset
sysparm_offset string

Number of records to exclude from the query. Use this parameter to get more records than specified in sysparm_limit. For example, if sysparm_limit is set to 500, but there are additional records you want to query, you can specify a sysparm_offset value of 500 to get the second set of records. Default: 0

sysparm_query
sysparm_query string

Encoded query. Queries for the Attachment API are relative to the Attachments [sys_attachment] table. For example: (sysparm_query=file_name=attachment.doc)

Get Knowledge Articles

Returns a list of knowledge base (KB) articles which can be searched and filtered

Parameters

Name Key Required Type Description
Fields
fields string

Comma-separated list of fields from the Knowledge table.

Limit
limit integer

Maximum number of records to return.

Query
query True string

Text to search for.

Filter
filter string

Encoded query to use to filter the result set.

Kb
kb string

Comma-separated list of knowledge base sys_ids.

Returns

Get Record

Gets a record for a ServiceNow object type like 'Incidents'

Parameters

Name Key Required Type Description
Record Type
tableType True string

Type of record to list

System ID
sysid True string

System ID for the record.

Display System References
sysparm_display_value boolean

Determines if system references should be included

Exclude Reference Links
sysparm_exclude_reference_link boolean

Determines if reference links should be excluded

Returns

The outputs of this operation are dynamic.

Get Record Types

Lists the available record types

Returns

List Records

Gets records of a certain ServiceNow object type like 'Incidents'

Parameters

Name Key Required Type Description
Record Type
tableType True string

Type of record to list

Display System References
sysparm_display_value boolean

Determines if system references should be included

Exclude Reference Links
sysparm_exclude_reference_link boolean

Determines if reference links should be excluded

Query
sysparm_query string

Encoded query used to filter the result set. Example: active=true^ORDERBYnumber^ORDERBYDESCcategory

Limit
sysparm_limit integer

Limit to be applied on pagination. The default is 10000.

Offset
sysparm_offset integer

Number of records to exclude from the query.

Returns

The outputs of this operation are dynamic.

Retrieve attachment content (Preview)

Retrieve attachment content

Parameters

Name Key Required Type Description
sys_id
sys_id True string

Retrieve attachment metadata (Preview)

Retrieve attachment metadata

Parameters

Name Key Required Type Description
sys_id
sys_id True string

Update Record

Updates a record for a ServiceNow object type like 'Incidents'

Parameters

Name Key Required Type Description
Record Type
tableType True string

Type of record to list

System ID
sysid True string

System ID for the record.

body
body True dynamic
Display System References
sysparm_display_value boolean

Determines if system references should be included

Exclude Reference Links
sysparm_exclude_reference_link boolean

Determines if reference links should be excluded

Returns

The outputs of this operation are dynamic.

Upload an attachment (Preview)

Upload an attachment from a multipart form

Parameters

Name Key Required Type Description
attachment_content
attachment_content True file

Attachment to upload

table_name
table_name True string

Name of the table to which you want to attach the file.

table_sys_id
table_sys_id True string

Sys_id of the record on the specified table to which you want to attach the file

Returns

Definitions

UploadAttachmentResponse

Name Path Type Description
average_image_color
result.average_image_color string

If the attachment is an image, the sum of all colors.

compressed
result.compressed string

Flag that indicates whether the attachment file has been compressed.

content_type
result.content_type string

Content-type of the associated attachment file, such as image or jpeg or application/x-shockwave-flash.

created_by_name
result.created_by_name string

Full name of entity that originally created the attachment file.

download_link
result.download_link string

Download URL of the attachment on the ServiceNow instance.

file_name
result.file_name string

File name of the attachment.

image_height
result.image_height string

If an image file, the height of the image. Unit: Pixels

image_width
result.image_width string

If an image file, the width of the image. Unit: Pixels

size_bytes
result.size_bytes string

Size of the attachment. Unit: Bytes

size_compressed
result.size_compressed string

Size of the attachment. Unit: Bytes

sys_created_by
result.sys_created_by string

Entity that originally created the attachment file.

sys_created_on
result.sys_created_on string

Date and time that the attachment file was initially saved to the instance.

sys_id
result.sys_id string

Sys_id of the attachment file.

sys_mod_count
result.sys_mod_count string

Number of times the attachment file has been modified (uploaded to the instance).

sys_tags
result.sys_tags string

Any system tags associated with the attachment file.

sys_updated_by
result.sys_updated_by string

Any system tags associated with the attachment file.

sys_updated_on
result.sys_updated_on string

Date and time that the attachment file was last updated.

table_name
result.table_name string

Name of the table to which the attachment is associated.

table_sys_id
result.table_sys_id string

Sys_id of the table associated with the attachment.

updated_by_name
result.updated_by_name string

Full name of entity that last updated the attachment file.

GetTypesResponse

Name Path Type Description
result
result array of object

Result set of all record types for current instance.

Display name
result.label string

Display name of the record type.

Value
result.value string

Value of the record type.

GetArticlesResponse

Name Path Type Description
Count
meta.count integer

Number of available KB articles

End
meta.end integer

Ending index of the result set

Fields
meta.fields string

Fields in the article

Filter
meta.filter string

Filter used to acquire the data

Kb
meta.kb string

List of knowledge base article sys_ids

Language
meta.language string

List of comma-separated languages of the KB articles that were requested

Query
meta.query string

Specified request query

Start
meta.start string

Starting index of result set

Status
meta.status.code string

Status of the call

Kb
meta.ts_query_id string

List of comma-separated languages of the KB articles that were requested

articles
articles array of object
Display Value
articles.fields.display_value string

Display value of the requested field

Label
articles.fields.label string

Label representing the requested field

Name
articles.fields.name string

Name of the requested field

Type
articles.fields.type string

Data type of requested field

Value
articles.fields.value string

Value of the requested field

Link
articles.Link string

Link to the article

id
articles.id string

Knowledge article sys_id from the Knowledge [kb_knowledge] table

Number
articles.number string

Knowledge article sys_id from the Knowledge [kb_knowledge] table

Rank
articles.rank float

Search rank of article specific to this search

Score
articles.score float

Relevancy score, results sorted in descending order by score

Snippet
articles.snippet string

Text showing a small portion of the knowledge article

Title
articles.title string

Short description or title of the knowledge article
